Non-Illum Selector Swtch, Momentary, Cam C - 9001KS53FBH1

Non-Illum Selector Swtch, Momentary, Cam C - 9001KS53FBH1

Schneider Electric
SKU:
9001KS53FBH1
|
UPC:
785901035268
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Selector Switch, 30 mm, 3 Position, Momentary/Maintained/Momentary Action, 1NO/1NC Contact Form, Type of Operator Extended Lever, Color Black, No Key Key Removal, Operator Head Material Polycarbonate, Basic Material Metal, Bezel Material Metal, Bezel Color Chrome, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/Q600, NEMA Rating 12, 13, 3, 3R, 4, IP Rating IP65, Cam C, Switch Operation @ Position A OX, Switch Operation @ Position B OO, Switch Operation @ Position C XO
Additional Information
Country of Origin:
Mexico
Item:
Selector Switch
Size:
30 mm
Basic Material:
Metal
Type of Operator:
Extended Lever
Action:
Momentary/Maintained/Momentary
Contact Form:
1NO/1NC
Operator Head Material:
Polycarbonate
Cam:
C
Color:
Black
NEMA Rating:
12, 13, 3, 3R, 4
Position:
3
Bezel Material:
Metal
Bezel Color:
Chrome
Key Removal:
No Key
Standards:
CE, CSA LR24590 Class 3211 03, UL E42259 CCN NKCR
Switch Operation @ Position A:
OX
Switch Operation @ Position B:
OO
Contact Rating:
10A @ 600V AC
NEMA Contact Rating Designation:
A600/Q600
Switch Operation @ Position C:
XO
IP Rating:
IP65
Switch Operation @ Position D:
No Fourth Position
Lamp Module Type:
Not Applicable
Lamp Type:
Not Applicable
DC Contact Rating:
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @125 V
Series:
9001K
AC Contact Rating:
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
Product Certifications:
CE || UL listed file E42259 CCN NKCR || CSA LR24590 class 3211 03
Mounting Diameter:
30 mm
Product Or Component Type:
selector switch
Device Presentation:
complete product
Operator Position Information:
3 positions
Contacts Type And Composition:
1 C/O
Cap/Operator Or Lens Colour:
black
Cam Profile:
3
Connections - Terminals:
screw-clamp terminals, 1 x 0.22 to 2 x 1.5 mm² IEC 60947-1
Nema Degree Of Protection:
NEMA 1/2/3/3R/4/6/12/13
Operator Profile:
black gloved hand knob, long handle
Return:
both sides to centre
Device Short Name:
K
Number of Positions:
3
Switch Function @ 4th Position:
No Fourth Position
Operator Head Color:
Black
Includes Operator Key:
Not Applicable
NEMA Enclosure Rating:
1, 12, 13, 2, 3, 3R, 4
Manufacturer Warranty Length:
18 mo
Operator Head Type:
Long-Handled Knob
Key Removal Position:
Not Applicable
Switch Function @ 3rd Position:
Momentary
Switch Function @ 2nd Position:
Off
Contact Block Material:
Metal
Metal Operator Head Finish:
Not Applicable
Hazardous Location Specification:
Not Rated
Operator Illumination:
Non-Illuminated
Switch Function @ 1st Position:
Momentary
Panel Cutout Diameter:
30 mm
Lamp Voltage - Maximum:
Not Applicable
Package Quantity:
1
