Non-Illum Push Button Operator, 30mm - 9001SKRU3

Non-Illum Push Button Operator, 30mm - 9001SKRU3

Schneider Electric
SKU:
9001SKRU3
|
UPC:
785901525509
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Pendant Push Button, 30 mm, Momentary/Momentary Action, Full Guard Type of Operator, Head Material Plastic, Contact Form Not Applicable, Bezel Double-insulated Plastic, Number of Operators 2, NEMA Rating 1, 12, 13, 2, 3, 3R, 4, 6, IP Rating IP66, Legend Not Applicable, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C4520, JIS C852, REACH, RoHS, UL 508, Terminal Connection Screw Clamp
Additional Information
Country of Origin:
Mexico
Action:
Momentary/Momentary
Size:
30 mm
Head Material:
Plastic
NEMA Rating:
1, 12, 13, 2, 3, 3R, 4, 6
Type of Operator:
Full Guard
Lamp Type:
Not Applicable
Contact Form:
Not Applicable
Legend:
Not Applicable
Number of Operators:
2
Item:
Pendant Push Button
Bezel Material:
Plastic
For Use With:
Class 9001 Type SK
Mechanical Interlock:
Yes
Standards:
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C4520, JIS C852, REACH, RoHS, UL 508
Terminal Connection:
Screw Clamp
IP Rating:
IP66
Series:
9001SK
Lamp Module Type:
Not Applicable
DC Contact Rating:
0.2 A @ 600 V, 0.55 A @ 240 V, 1.1 A @ 120 V
AC Contact Rating:
1.5 A @ 240 V, 3 A @ 120 V
Nema Degree Of Protection:
NEMA 1/2/3/3R/4/4X/6/12/13
Ip Degree Of Protection:
IP66
Contact Operation:
standard
Device Presentation:
basic element
Mechanical Durability:
5000000 cycles
Product Or Component Type:
push-button
Device Short Name:
9001SK
Mounting Diameter:
30 mm
Product Type:
Push Button Operators
Push Button Style:
Extended
Resistance Properties:
Dust Resistant, Impact Resistant, Vibration Resistant, Watertight
Head Color:
Black
Number of Indicator Lights:
0
Panel Cutout Diameter:
30 mm
Legend Color:
Not Applicable
NEMA Enclosure Rating:
1, 12, 13, 2, 3, 3R, 4, 4X, 6
Operator Voltage Rating - Maximum:
600 V AC
Operating Temperature - Minimum:
-22 Degrees F
Legend Background Color:
Not Applicable
Hazardous Location Specification:
Class I, Div 2, Group A, B, C, D, Class II, Div 2, Group E, F, G, Class III, Div 1 and 2
Operator Illumination:
Non-Illuminated
Manufacturer Warranty Length:
18 mo
Operating Temperature - Maximum:
140 Degrees F
Operator Material:
Plastic
Lamp Voltage - Maximum:
Not Applicable
Maintained Action Release:
Not Applicable
Mechanical Operating Durability:
5.00 x 10^6
Mushroom Head Diameter:
Not Applicable
Package Quantity:
1
