Multiprocess Welder, LE31MP(R), Phase 1 , 120 , DC TIG, Flux-Cored, MIG, Stick , 95A @ 18.75V DC - K3461-1

Multiprocess Welder, LE31MP(R), Phase 1 , 120 , DC TIG, Flux-Cored, MIG, Stick , 95A @ 18.75V DC - K3461-1

Lincoln Electric
SKU:
K3461-1
|
UPC:
15082833736
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Multiprocess Welder, Series LE31MP(R), Input Voltage 120V AC, Phase Single-Phase, Welding Mode CV, Polarity DC, Input Frequency 60 Hz, Welding Processes Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW), Stick Welding Maximum Output Current 90 A, TIG Welding Maximum Output Current 120 A, MIG Welding Maximum Output Current 95 A, For Wire Type Flux-Cored, Solid, Maximum Wire Diameter 0.035 in (Flux-Cored), Maximum Wire Feed Speed 500 in/min, Model K3461-1
Additional Information
Country of Origin:
Mexico
Item:
Multiprocess Welder
Series:
LE31MP(R)
Phase:
Single-Phase
Input Voltage:
120V AC
Function:
DC TIG, Flux-Cored, MIG, Stick
Rated Output:
95A @ 18.75V DC
Overall Width (In.):
18 7/64 in
Mild Steel - Material Thickness:
24 ga to 5/16 in
Output Range:
100 to 120A, 25 to 90A, 30 to 140A
Overall Height (In.):
8 29/32 in
Aluminum - Material Thickness:
18 ga to 1/4 in
Standards:
CSA
Stainless Steel - Material Thickness:
18 ga to 1/4 in
Input (Amps):
20
Application:
Auto Body, Farm, Home, Shop
Hz:
60
Wire Size:
0.025 in to 0.035 in
Overall Depth (In.):
13 39/64 in
Welding Processes:
Flux-Cored Welding (FCAW), MIG Welding (GMAW), Stick Welding (SMAW), TIG Welding (GTAW)
Features:
Adjustable Drive System, Brass-to-Brass Gun Connection, Durable Cast Aluminum Gear Box, Easy-Turn Numeric Drive Tension Indicator, Simple (2) Knob Control
Amperage Range:
10 A to 140 A
Duty Cycle:
60%
Amps AC:
140
Includes:
(3) 0.025 in Tapered Contact Tips (KH831), (3) 0.035 in Tapered Contact Tips (KH833), 0.025 - 0.035 in Dual Track Drive Roll for MIG & Flux-Cored Welding (KP2948-1), Gas Nozzle for MIG Welding (KH835), Gasless Nozzle for Flux-Cored Welding (KH836), H
For Maximum Material Thickness:
1/4 in (Aluminum), 1/4 in (Stainless Steel), 5/16 in (Mild Steel)
TIG Welding Maximum Output Current:
120 A
Input Frequency:
60 Hz
Stick Welding Output @ Duty Cycle:
80 A @ 23.2 V, 60%
Effective Input Current:
20 A @ 120V DC (Single-Phase)
Overall Width:
18.11 in
Overall Depth:
13.61 in
TIG Welding Output @ Duty Cycle:
115 A @ 14.6 V, 60%
TIG Welding Minimum Output Current:
10 A
Minimum Wire Diameter:
0.025 in (Flux-Cored)
Stick Welding Minimum Output Current:
25 A
Polarity:
DC
Overall Height:
8.91 in
Maximum Wire Diameter:
0.035 in (Flux-Cored)
Stick Welding Maximum Output Current:
90 A
Maximum Wire Feed Speed:
500 in/min
Max. Input Current:
20 A
For Minimum Material Thickness:
1/20 in (Aluminum), 1/20 in (Stainless Steel), 1/40 in (Mild Steel)
For Wire Type:
Flux-Cored, Solid
Welding Mode:
CV
Minimum Wire Feed Speed:
40 in/min
Color:
Red
MIG Welding Minimum Output Current:
20 A
MIG Welding Output @ Duty Cycle:
95 A @ 18.75 V, 60%
MIG Welding Maximum Output Current:
95 A
Weight:
34.5 lb
Model:
K3461-1
Package Quantity:
1
