Multi-Size Pneumatic Test Plug 8" to 12" - 83282

Multi-Size Pneumatic Test Plug 8" to 12" - 83282

Test-Tite
SKU:
83282
|
UPC:
12181832820
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Test Plug, Air Connection Gender Male, Air Connection Size 1/4 in, Air Connection Type NPT, Body Surface Style Textured, Bypass Connection Size Not Applicable, Bypass Connection Type Not Applicable, Bypass Thread Gender Not Applicable, Deflated Diameter 17.5 in, Deflated Length 15.75 in, For Maximum Pipe Inside Diameter 12.25 in, For Maximum Pipe Size 12 in, For Minimum Pipe Inside Diameter 7.09 in, For Minimum Pipe Size 8 in, Head Tether Connection Handle and Chain, Inflated Length 17.5 in
Additional Information
Country of Origin:
United States
Material:
Rubber
Max. Diameter:
12.25 in
Nominal Size:
8 to 12 in
For Use In:
DWV Systems to Seal Round and Out of Round Pipe; To Testing of Pipelines or to Temporarily Stop the Flow
Min. Dia.:
7.09 in
Max. Back Pressure:
40 ft of Head
Type:
Pneumatic Test Plug
Required Inflation Pressure:
30 psi
Deflated Size:
17.50 in
Item:
Test Plug
Includes:
Pressure-Relief Valve
Deflated Diameter:
17.5 in
For Minimum Pipe Size:
8 in
Deflated Length:
15.75 in
Maximum Back Pressure (Air):
17 psig
Air Connection Gender:
Male
Air Connection Size:
1/4 in
Number of Inflation Chambers:
1
For Maximum Pipe Inside Diameter:
12.25 in
Bypass Connection Size:
Not Applicable
Application:
Testing of Pipelines, Temporarily Stop the Flow
Plug Seal Material:
Natural Rubber
Maximum Back Pressure (Water):
40 ft of head
For Use On:
Drain, Vent, Waste
For Minimum Pipe Inside Diameter:
7.09 in
Features:
Replaceable Tank Valve
Body Surface Style:
Textured
Head Tether Connection:
Handle and Chain
Inflated Length:
17.5 in
Test Plug Weight:
8.75 lb
Includes Protective Sleeve:
No
Air Connection Type:
NPT
Bypass Connection Type:
Not Applicable
For Maximum Pipe Size:
12 in
Bypass Thread Gender:
Not Applicable
Contains Pressure Release Valve:
Yes
Package Quantity:
1
