Mtr, 1/2HP, 1140RPM, 115V - 6XJ56

Mtr, 1/2HP, 1140RPM, 115V - 6XJ56

Dayton
SKU:
6XJ56
|
UPC:
190735373576
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
General Purpose Motor, Single Phase, Motor Design Split Phase, 1/2 hp HP, Nameplate RPM 1,140, No. of Speeds 1, Voltage 115V AC, Full Load Amps 8.7 A, 56 Frame, Hz 60 Hz, Motor Service Factor 1, Max. Ambient Temp. 40 Degrees C, Motor Thermal Protection None, Duty Cycle Continuous, Ins. Class B, Motor Enclosure Design Totally Enclosed Fan Cooled, Motor Shaft Rotation CW/CCW, Motor Mounting Type Cradle Base, Motor Shaft Design Keyed, Motor Frame Material Steel
Additional Information
Country of Origin:
Mexico
Motor Service Factor:
1
No. of Speeds:
1
Manufacturers Warranty Length:
1 yr
RPM Group:
1101-1200
Motor Thermal Protection:
None
HP:
1/2 hp
Length Less Shaft:
11 3/8 in
Overall Length:
13 5/16 in
Max. Ambient Temp.:
40 Degrees C
Motor Application:
General Purpose
Footnotes:
40
Motor Shaft Design:
Keyed
RPM Range:
1,101-1,200
Full Load Amps:
8.7 A
Motor Enclosure Design:
Totally Enclosed Fan Cooled
Voltage Compatibility:
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Nominal Efficiency:
63.4 %
Frame Material:
Rolled steel
Motor Shaft Rotation:
CW/CCW
Standards:
CSA (258501), UL (E47479)
Motor Efficiency Group:
Standard Efficient
Phase:
Single
Duty:
Continuous
Frame:
56
Shaft Length:
1 7/8 in
Voltage:
115V AC
Hz:
60 Hz
Motor Design:
Split Phase
Shaft Dia.:
5/8 in
Item:
General Purpose Motor
Motor Mounting Type:
Cradle Base
Motor Frame Material:
Steel
Motor Bearings:
Ball
Nameplate RPM:
1,140
Ins. Class:
B
Duty Cycle:
Continuous
RPM @ 50Hz:
Not Applicable
Voltage @ 50Hz:
Not Applicable
Service Factor @ 50Hz:
Not Applicable
Full Load Amps @ 50Hz:
Not Applicable
HP @ 50Hz:
Not Applicable
Package Quantity:
1
