Motor, PSC, 1/3 HP, 1100 RPM, 115V, 56Z, ODP - 6TWL4

Motor, PSC, 1/3 HP, 1100 RPM, 115V, 56Z, ODP - 6TWL4

Dayton
SKU:
6TWL4
|
UPC:
190735371657
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Direct Drive Blower Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/3 HP, Nameplate RPM 1,100, No. of Speeds 1, Voltage 115V AC, Full Load Amps 4.7 A, 56Z Frame, Usable @ 208V No, Usable @ 200V No, Motor Thermal Protection Auto, 60 Hz Hz, Motor Service Factor 1, Ins. Class B, Motor Shaft Rotation CW/CCW, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Enclosure Design Open Dripproof, Motor Mounting Type Face, Motor Mounting Position All Angle, Number of Shafts 1
Additional Information
Country of Origin:
United States
Frame:
56Z
RPM Range:
1,001-1,100
Voltage:
115V AC
Motor Service Factor:
1
Motor Enclosure Design:
Open Dripproof
Phase:
Single
Motor Sub Application:
Direct Drive
Nameplate RPM:
1,100
Standards:
CSA Certified (225293), CSA Certified Motor, UL Recognized (E47479)
Length Less Shaft:
8 5/8 in
Bolt Circle Dia.:
5 1/8 in
Shaft Length:
4 1/4 in
Stud Size:
#10-32
Nominal Efficiency:
0.6 %
Mounting Stud Location:
Shaft End
Resilient Ring Dia.:
2 1/4 in
Duty:
Continuous
Ins. Class:
B
Body Dia.:
5 5/8 in
Motor Shaft Design:
Keyed
Motor Shaft Rotation:
CW/CCW
Mounting Stud Length:
1 in
Overall Length:
12 7/8 in
HP:
1/3
Max. Ambient Temp.:
40 Degrees C
Motor Mounting Position:
All Angle
Full Load Amps:
4.7 A
Motor Thermal Protection:
Auto
Motor Bearings:
Ball
Item:
Direct Drive Blower Motor
Hz:
60 Hz
Motor Application:
HVAC/R
Ring to Ring Center:
8 1/8 in
Mounting Stud Pattern:
3-5/8 in x 3-5/8 in
Voltage Compatibility:
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Motor Mounting Type:
Face
Motor Design:
Permanent Split Capacitor
Capacitor Required:
Included
Manufacturers Warranty Length:
1 yr
No. of Speeds:
1
Shaft Dia.:
5/8 in
Stud Quantity:
4
Duty Cycle:
Continuous
Mounting Holes:
(4) #10-32
Usable @ 200V:
No
Number of Shafts:
1
Includes:
Capacitor
Usable @ 208V:
No
Conduit Box Position:
F3
Mounting:
Cradle Base
Number of Speeds:
1
Package Quantity:
1
