Motor, 1/2 HP, Jet Pump - 5K657BG
DaytonLog in for pricing
(No reviews yet)
Write a Review
Dayton
Motor, 1/2 HP, Jet Pump - 5K657BG
Jet Pump Motor, Body Dia. 5.6 in, Finish Gray, Frame 56C, Hz 60 Hz, Full Load Amps 7.7/3.8, HP 1/2, Includes Dripcover Kit for Vertical Mounting, Shaft Key, Ins. Class B, Max. Ambient Temp. 40 Degrees C, Motor Application Pump, Motor Bearings Ball, Motor Design Capacitor-Start, Motor Efficiency Group Standard Efficient, Motor Enclosure Design Open Dripproof
- Country of Origin:
- Multiple
- Motor Application:
- Pump
- Nominal Efficiency:
- 57.8 %
- Body Dia.:
- 5.6 in
- Motor Sub Application:
- Jet Pump
- Nameplate RPM:
- 3,450
- Hz:
- 60 Hz
- Shaft Dia.:
- 5/8 in
- Motor Mounting Type:
- Face
- Ins. Class:
- B
- Full Load Amps:
- 7.7/3.8
- Motor Design:
- Capacitor-Start
- Item:
- Jet Pump Motor
- Motor Service Factor:
- 1.6
- Voltage Compatibility:
- 115/200-230V AC, 115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 230V AC, 240V AC
- Standards:
- CSA Certified (701848 and 258501), UL Recognized (E37403)
- Motor Shaft Design:
- Keyed
- Voltage:
- 115/230V AC
- Motor Enclosure Design:
- Open Dripproof
- Frame:
- 56C
- Motor Shaft Rotation:
- CCWSE
- Includes:
- Dripcover Kit for Vertical Mounting, Shaft Key
- Motor Thermal Protection:
- Auto
- Phase:
- Single
- Shaft Length:
- 1 7/8 in
- RPM Range:
- 3,001-3,600
- HP:
- 1/2
- Motor Mounting Position:
- Horizontal, Vertical Shaft Down
- Max. Ambient Temp.:
- 40 Degrees C
- Motor Bearings:
- Ball
- Finish:
- Gray
- Shaft Dia. (In.):
- 5/8
- Shaft Type:
- Keyed
- Package Quantity:
- 1
