Molded Case Circuit Breaker, JG Series, 100A, 3 Pole, 600V AC, 25kA at 240V AC - JGE3100FAG

Molded Case Circuit Breaker, JG Series, 100A, 3 Pole, 600V AC, 25kA at 240V AC - JGE3100FAG

Eaton
SKU:
JGE3100FAG
|
UPC:
782113962511
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Molded Case Circuit Breaker, 100 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 25kA at 240V AC, For Use With Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse, Series JG, High Amp Trip Setting 250 A, Low Amp Trip Setting 20 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 250V DC, Terminal Connection Line/Load Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC
Additional Information
Country of Origin:
Dominican Republic
Item:
Molded Case Circuit Breaker
Series:
JG
Amps:
100A
Number of Poles:
3
AC Voltage Rating:
600V AC
Circuit Breaker Type:
Standard
Phase:
3
Circuit Breaker Actuator:
Toggle
Circuit Breaker Mounting Style:
Free Standing
Max. AIR Rating:
25kA at 240V AC
Trip Type:
Thermal Magnetic
Instantaneous Trip:
Fixed
Terminal Connection:
Line/Load Lug
Phase Connection:
ABC
Frame Size:
250A/JG
Width:
4.13 in
Depth:
3.44 in
Height:
7 in
DC Voltage Rating:
250V DC
Low Amp Trip Setting:
20 A
For Use With:
Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
Min. Wire Size:
14 AWG
Standards:
CSA Certified, IEC Rated, UL Listed
High Amp Trip Setting:
250 A
Max. Wire Size:
1/0 AWG
Interrupt Rating:
65 kA at 240V AC
Frame Type:
Complete Breaker
Min. Operating Temp.:
-4 Degrees F
Max. Operating Temp.:
158 Degrees F
Compliances:
CE Marked
Certifications:
IEC Rated;CSA Certified;UL Listed
Product Name:
Eaton Series G complete molded case circuit breaker
Frequency Rating:
50/60 Hz
Mounting:
Free Standing
Package Quantity:
1
