Molded Case Circuit Breaker, HMCP Series, 3A, 3 Pole, 600V AC, 65kA at 600V AC - HMCPS003A0C

Molded Case Circuit Breaker, HMCP Series, 3A, 3 Pole, 600V AC, 65kA at 600V AC - HMCPS003A0C

Eaton
SKU:
HMCPS003A0C
|
UPC:
786679804247
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Molded Case Circuit Breaker, 3 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 65kA at 600V AC, For Use With Motor Starters Equipped with Electronic Overload Relays, Series HMCP, High Amp Trip Setting 2.5 A, Low Amp Trip Setting 0.69 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating 250V DC, Terminal Connection Line/Load Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 250A/J
Additional Information
Country of Origin:
Dominican Republic
Item:
Molded Case Circuit Breaker
Series:
HMCP
Amps:
3A
Number of Poles:
3
AC Voltage Rating:
600V AC
Circuit Breaker Type:
Standard
Phase:
3
Circuit Breaker Actuator:
Toggle
Circuit Breaker Mounting Style:
Free Standing
Max. AIR Rating:
65kA at 600V AC
Trip Type:
Thermal Magnetic
Instantaneous Trip:
Fixed
Terminal Connection:
Line/Load Lug
Phase Connection:
ABC
Frame Size:
250A/J
Width:
5.1 in
Depth:
7.6 in
Height:
4.8 in
DC Voltage Rating:
250V DC
Standards:
CSA Certified, IEC Rated, UL Listed
Min. Wire Size:
14 AWG
Low Amp Trip Setting:
0.69 A
For Use With:
Motor Starters Equipped with Electronic Overload Relays
Max. Wire Size:
1/0 AWG
High Amp Trip Setting:
2.5 A
Max. Operating Temp.:
158 Degrees F
Min. Operating Temp.:
-4 Degrees F
Used With:
Electric starters
Product Name:
Eaton molded case circuit breaker accessory motor protection
Certifications:
UL Listed;CSA Certified
Terminal Material:
Non-aluminum
Magnetic Trip Range:
9-30 A
Mounting:
Free Standing
Package Quantity:
1
