Mixing Valve, Lead Free Brass, 125 psi - LFSH1434 W/TP GAUGE

Mixing Valve, Lead Free Brass, 125 psi - LFSH1434 W/TP GAUGE

Powers
SKU:
LFSH1434 W/TP GAUGE
|
UPC:
98268793840
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Thermostatic Mixing Valve, Body Material Bronze, Flow Rate 127 gpm at 45 psi, Inlet Type NPT, Outlet Type NPT, Inlet Size 1 1/4 in, Outlet Size 1 1/2 in, Temp. Range 90 Degrees to 160 Degrees F, Max. Pressure 125 psi, Overall Height 9 1/4 in, Overall Width 15 1/2 in, Inlet Temperature (Cold) 40 Degrees to 80 Degrees F, Inlet Temperature (Hot) 120 Degrees to 180 Degrees F, Standards ASSE 1017, CSA B125
Additional Information
Country of Origin:
United States
Item:
Thermostatic Mixing Valve
Body Material:
Bronze
Flow Rate:
127 gpm at 45 psi
Inlet Type:
NPT
Outlet Type:
NPT
Inlet Size:
1 1/4 in
Outlet Size:
1 1/2 in
Temp. Range:
90 Degrees to 160 Degrees F
Max. Pressure:
125 psi
Standards:
ASSE 1017, CSA B125
Overall Height:
9 1/4 in
Overall Width:
15 1/2 in
Inlet Temperature (Cold):
40 Degrees to 80 Degrees F
Inlet Temperature (Hot):
120 Degrees to 180 Degrees F
Size:
1-1/4 x 1-1/2";Connection=Threaded"
Material of Construction:
Lead Free Brass
Overall Length:
15 1/2 in
Valve Type:
Thermostatic
Coefficient of Volume (Cv):
19
Inlet Connection Type - Hot:
NPT
Inlet Temperature - Maximum Cold:
80 Degrees F
Operating Pressure - Maximum:
125 psi
For Media:
Hot Water, Water
Operating Temperature - Minimum Outlet:
90 Degrees F
Includes Temperature Gauge:
Temperature Gauge Included
Outlet Connection Size:
1 1/2 in
Operating Pressure - Minimum:
Not Applicable
Inlet Temperature - Maximum Hot:
180 Degrees F
Operating Temperature - Maximum Outlet:
160 Degrees F
Inlet Connection Size - Cold:
1 1/4 in
Inlet Connection Size - Hot:
1 1/4 in
Seal Material:
Not Applicable
Inlet Connection Type - Cold:
NPT
Outlet Connection Type:
NPT
Inlet Temperature - Minimum Cold:
40 Degrees F
Inlet Temperature - Minimum Hot:
120 Degrees F
Package Quantity:
1
