Miniature Circuit Breaker, QOB Series, 50A, 2 Pole, 120/240V AC, 22kA at 120/240V AC - QOB250VH

Miniature Circuit Breaker, QOB Series, 50A, 2 Pole, 120/240V AC, 22kA at 120/240V AC - QOB250VH

Square D
SKU:
QOB250VH
|
UPC:
785901054771
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Miniature Circuit Breaker, Amps 50 A, AC Voltage Rating 120/240V AC, Circuit Breaker Type High Interrupting Capacity, Number of Poles 2, DC Voltage Rating Not Rated, Circuit Breaker Actuator Paddle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series QO, Phase Single, Series QOB, Max. AIR Rating 22kA at 120/240V AC, For Use With Square D NQOD Panelboards, Terminal Connection Lug, Frame Size 100A/QO, Length 3.12 in, Width 1.5 in, Depth 2.91 in
Additional Information
Country of Origin:
Mexico
Item:
Miniature Circuit Breaker
Series:
QOB
Amps:
50A
Number of Poles:
2
AC Voltage Rating:
120/240V AC
Circuit Breaker Type:
Standard
Phase:
1
Circuit Breaker Actuator:
Paddle
Circuit Breaker Mounting Style:
Bolt On
Max. AIR Rating:
22kA at 120/240V AC
Terminal Connection:
Lug
Frame Size:
100A/QO
Width:
1.5 in
Depth:
2.91 in
Height:
3.11 in
DC Voltage Rating:
Not Rated
Max. Wire Size:
2 AWG
For Use With:
Square D NQOD Panelboards
Min. Wire Size:
8 AWG
Standards:
UL Listed
Application:
HACR rated Applications
Interrupt Rating:
22 kA at 120/240V AC
Features:
Mercury Free
Min. Operating Temp.:
77 Degrees F
Compatible Panelboard/Load Center Series:
QO
Max. Operating Temp.:
104 Degrees F
Length (Straight Wireway):
3.12 in
Length:
3.12 in
Voltage:
120/240 VAC
Mounting:
Bolt on
Package Quantity:
1
