Miniature Circuit Breaker, QO Series, 60A, 3 Pole, 120/240V AC, 22kA at 120/240V AC - QO360VH

Miniature Circuit Breaker, QO Series, 60A, 3 Pole, 120/240V AC, 22kA at 120/240V AC - QO360VH

Square D
SKU:
QO360VH
|
UPC:
785901060222
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Miniature Circuit Breaker, Amps 60 A, AC Voltage Rating 120/240V AC, Circuit Breaker Type High Interrupting Capacity, Number of Poles 3, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Plug In, Compatible Panelboard/Load Center Series QO, Phase Three, Series QO, Max. AIR Rating 22kA at 120/240V AC, For Use With QO Load Centers and NQ Panelboards, Terminal Connection Lug, Frame Size 100A/QO, Length 3.12 in, Width 2.25 in, Depth 2.91 in
Additional Information
Country of Origin:
Mexico
Item:
Miniature Circuit Breaker
Series:
QO
Amps:
60A
Number of Poles:
3
AC Voltage Rating:
120/240V AC
Circuit Breaker Type:
High Interrupting Capacity
Phase:
3
Circuit Breaker Actuator:
Toggle
Circuit Breaker Mounting Style:
Plug In
Max. AIR Rating:
22kA at 120/240V AC
Terminal Connection:
Lug
Frame Size:
100A/QO
Width:
2.25 in
Depth:
2.91 in
Height:
3.11 in
DC Voltage Rating:
Not Rated
Max. Wire Size:
2 AWG
Standards:
UL Listed
For Use With:
QO Load Centers and NQ Panelboards
Min. Wire Size:
8 AWG
Features:
Mercury Free
Interrupt Rating:
22 kA at 120/240V AC
Application:
HACR rated Applications
Compatible Panelboard/Load Center Series:
QO
Length (Straight Wireway):
3.12 in
Tightening Torque:
49.56 lbf.in (5.6 N.m)
Certifications:
UL Listed; CSA
Wire Size:
AWG 8 to AWG 2 copper or aluminium
Ratings:
HACR rated
Ambient Temperature Rating:
104°F (40°C)
Voltage:
240VAC
Length:
3.12 in
Package Quantity:
1
