Miniature Circuit Breaker, QO Series, 100A, 3 Pole, 120/240V AC, 22kA at 120/240V AC - QO3100VH

Miniature Circuit Breaker, QO Series, 100A, 3 Pole, 120/240V AC, 22kA at 120/240V AC - QO3100VH

Square D
SKU:
QO3100VH
|
UPC:
785901060192
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Miniature Circuit Breaker, Amps 100 A, AC Voltage Rating 120/240V AC, Circuit Breaker Type High Interrupting Capacity, Number of Poles 3, DC Voltage Rating Not Rated, Circuit Breaker Actuator Paddle, Circuit Breaker Mounting Style Plug In, Compatible Panelboard/Load Center Series QO, Phase Three, Series QO, Max. AIR Rating 22kA at 120/240V AC, For Use With QO Load Centers and NQ Panelboards, Terminal Connection Lug, Frame Size 100A/QO, Length 3.5 in, Width 2.25 in, Depth 2.91 in
Additional Information
Country of Origin:
Mexico
Item:
Miniature Circuit Breaker
Series:
QO
Amps:
100A
Number of Poles:
3
AC Voltage Rating:
120/240V AC
Circuit Breaker Type:
Standard
Phase:
3
Circuit Breaker Actuator:
Paddle
Circuit Breaker Mounting Style:
Plug In
Max. AIR Rating:
22kA at 120/240V AC
Terminal Connection:
Lug
Frame Size:
100A/QO
Width:
2.24 in
Depth:
2.91 in
Height:
3.5 in
DC Voltage Rating:
Not Rated
Standards:
UL Listed
Max. Wire Size:
2 AWG
For Use With:
QO Load Centers and NQ Panelboards
Min. Wire Size:
4 AWG
Application:
HACR rated Applications
Interrupt Rating:
22 kA at 120/240V AC
Features:
Mercury Free
Compatible Panelboard/Load Center Series:
QO
Length (Straight Wireway):
3.5 in
Voltage:
240VAC
Length:
3.5 in
Package Quantity:
1
