Miniature Circuit Breaker, GHB Series, 30A, 1 Pole, 277V AC, 14kA at 277V AC - GHB1030

Miniature Circuit Breaker, GHB Series, 30A, 1 Pole, 277V AC, 14kA at 277V AC - GHB1030

Eaton
SKU:
GHB1030
|
UPC:
786679016466
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Miniature Circuit Breaker, Amps 30 A, AC Voltage Rating 277V AC, Circuit Breaker Type Standard, Number of Poles 1, DC Voltage Rating 125V DC, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series 1A, Phase Single, Series GHB, Max. AIR Rating 14kA at 277V AC, For Use With Eaton Powerline Panelboards, Terminal Connection Screw Clamp, Frame Size 100/GHB, Length 4 in, Width 1 in, Depth 2.63 in, Min. Operating Temp. -4 Degrees F
Additional Information
Country of Origin:
Dominican Republic
Item:
Miniature Circuit Breaker
Series:
GHB
Amps:
30A
Number of Poles:
1
AC Voltage Rating:
277V AC
Circuit Breaker Type:
Standard
Phase:
1
Circuit Breaker Actuator:
Toggle
Circuit Breaker Mounting Style:
Bolt On
Max. AIR Rating:
14kA at 277V AC
Trip Type:
Fixed Thermal Magnetic
Instantaneous Trip:
Fixed
Terminal Connection:
Screw Clamp
Frame Size:
100/GHB
Width:
1 in
Depth:
2.63 in
Height:
4 in
DC Voltage Rating:
125V DC
Min. Wire Size:
10 AWG
Standards:
CSA Certified, UL Listed
For Use With:
Eaton Powerline Panelboards
Max. Wire Size:
1/0 AWG
Frame Type:
Complete Breaker
Interrupt Rating:
14 kA at 277V AC
Min. Operating Temp.:
-4 Degrees F
Compatible Panelboard/Load Center Series:
1A
Max. Operating Temp.:
158 Degrees F
Length (Straight Wireway):
4.0 in
Compliances:
Federal Specifications Classification W-C375B
Product Name:
Eaton Series C complete molded case circuit breaker
Frequency Rating:
50/60 Hz
Frame:
G
Certifications:
UL Listed
Mounting:
Bolt on
Length:
4 in
Package Quantity:
1
