Miniature Circuit Breaker, GHB Series, 20A, 1 Pole, 277V AC, 14kA at 277V AC - GHB1020

Miniature Circuit Breaker, GHB Series, 20A, 1 Pole, 277V AC, 14kA at 277V AC - GHB1020

Eaton
SKU:
GHB1020
|
UPC:
786679023624
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Miniature Circuit Breaker, Amps 20 A, AC Voltage Rating 277V AC, Circuit Breaker Type Standard, Number of Poles 1, DC Voltage Rating 125V DC, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series 1A, Phase Single, Series GHB, Max. AIR Rating 14kA at 277V AC, For Use With Eaton Powerline Panelboards, Terminal Connection Screw Clamp, Frame Size 100/GHB, Length 4 in, Width 1 in, Depth 2.63 in, Min. Operating Temp. -4 Degrees F
Additional Information
Country of Origin:
Dominican Republic
Item:
Miniature Circuit Breaker
Series:
GHB
Amps:
20A
Number of Poles:
1
AC Voltage Rating:
277V AC
Circuit Breaker Type:
Standard
Phase:
1
Circuit Breaker Actuator:
Toggle
Circuit Breaker Mounting Style:
Bolt On
Max. AIR Rating:
14kA at 277V AC
Trip Type:
Fixed Thermal Magnetic
Instantaneous Trip:
Fixed
Terminal Connection:
Screw Clamp
Frame Size:
100/GHB
Width:
1 in
Depth:
2.63 in
Height:
4 in
DC Voltage Rating:
125V DC
Min. Wire Size:
14 AWG
Standards:
CSA Certified, UL Listed
For Use With:
Eaton Powerline Panelboards
Max. Wire Size:
10 AWG
Interrupt Rating:
14 kA at 277V AC
Frame Type:
Complete Breaker
Min. Operating Temp.:
-4 Degrees F
Max. Operating Temp.:
158 Degrees F
Compatible Panelboard/Load Center Series:
1A
Length (Straight Wireway):
4.0 in
Frequency Rating:
50/60 Hz
Frame:
G
Product Name:
Eaton Series C complete molded case circuit breaker
Compliances:
Federal Specifications Classification W-C375B
Certifications:
UL Listed
Length:
4 in
Mounting:
Bolt on
Package Quantity:
1
