Miniature Circuit Breaker, BQD Series, 35A, 1 Pole, 277V AC, 14kA at 277V AC - BQD135

Miniature Circuit Breaker, BQD Series, 35A, 1 Pole, 277V AC, 14kA at 277V AC - BQD135

Siemens
SKU:
BQD135
|
UPC:
783643277120
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Miniature Circuit Breaker, Amps 35 A, AC Voltage Rating 277V AC, Circuit Breaker Type Standard, Number of Poles 1, DC Voltage Rating 125V DC, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Compatible Panelboard/Load Center Series P1, Phase Single, Series BQD, Max. AIR Rating 14kA at 277V AC, For Use With Siemens P1 Panelboards, Terminal Connection Lug, Frame Size 100A/BQD, Length 4.49 in, Width 1 in, Depth 2.7 in, Max. Operating Temp. 104 Degrees F
Additional Information
Country of Origin:
Mexico
Item:
Miniature Circuit Breaker
Series:
BQD
Amps:
35A
Number of Poles:
1
AC Voltage Rating:
277V AC
Circuit Breaker Type:
Standard
Phase:
1
Circuit Breaker Actuator:
Toggle
Circuit Breaker Mounting Style:
Bolt On
Max. AIR Rating:
14kA at 277V AC
Terminal Connection:
Lug
Frame Size:
100A/BQD
Width:
1 in
Depth:
2.7 in
Height:
4.49 in
DC Voltage Rating:
125V DC
For Use With:
Siemens P1 Panelboards
Standards:
CSA-C22.2,UL 489
Max. Wire Size:
6 AWG
Min. Wire Size:
12 AWG (Al), 14 AWG (Cu)
Max. Operating Temp.:
104 Degrees F
Compatible Panelboard/Load Center Series:
P1
Length (Straight Wireway):
4.49 in
Mounting:
Bolt on
Length:
4.49 in
Voltage:
277VAC
Package Quantity:
1
