Mechanical Interlock - HBL460MIF12W

Mechanical Interlock - HBL460MIF12W

Hubbell
SKU:
HBL460MIF12W
|
UPC:
783585406008
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Mechanical Interlock Device, Circuit Breaker Amp Rating 60 A, Circuit Breaker Type Not Applicable, Current Rating 60 A, Fuse Protection Fused, Fuse Type Class J, NEMA Enclosure Rating Not Rated, Number of Poles 3, Number of Wires 4, Voltage Rating 120/240V AC, Grounding Grounded, Housing Material Thermoplastic, Maximum Wire Size 2 AWG, Phase Single, Resistance Properties Watertight, Standards CSA Certified, cULus, Viewing Window No, Reverse Service No
Additional Information
Country of Origin:
United States
Item:
Mechanical Interlock Device
Voltage:
125/250V AC
Amps:
60 A
Receptacle Type:
Pin and Sleeve
Number of Poles:
3
Phase:
Single
Number of Wires:
4
Viewing Window:
No
Fused / Nonfused:
Fused
Color:
orange
Standards:
CSA Certified, cULus
Grounding:
Grounded
Fuse Protection:
Fused
Includes Mounting Hardware:
Yes
Housing Material:
Thermoplastic
Overall Width:
10.18 in
Voltage Rating:
120/240V AC
Electrical Connection Type:
Pin and Sleeve
Circuit Breaker Amp Rating:
60 A
Overall Height:
15.36 in
Contact Material:
Brass
Maximum Operating Temperature:
75 Degrees C
Housing Color:
Orange
Resistance Properties:
Watertight
Fuse Type:
Class J
Reverse Service:
No
Current Rating:
60 A
UL 94 Flammability Rating:
5VA, V-0
IP Rating:
IP66
Minimum Operating Temperature:
-40 Degrees C
NEMA Enclosure Rating:
Not Rated
Circuit Breaker:
No
Circuit Breaker Type:
Not Applicable
Maximum Wire Size:
2 AWG
Minimum Wire Size:
8 AWG
Current Interrupting:
Certified for current interrupting at full rated current.
Shaft:
Brass
Ingress Protection:
IP67 Suitability
Gaskets:
Neoprene
Mechanical Interlock Device Standard:
IEC
Endurance:
Mechanical
Mechanical Interlock Items:
Complete Unit
Operating Temperatures:
Maximum Continuous
Terminal Accommodations:
#2 To #10 AWG copper wire only
Certifications:
UL Listed, CSA Certified.
Moisture Resistance:
Outdoor
Mating Plug:
HBL460P12W
Mounting Screws:
Stainless Steel (300 Series)
Enclosure Inserts:
Brass
Handle:
Valox
Base:
VALOX
UV Resistance:
All materials are UV Stabilized.
Terminal Identification:
Terminals identified in accordance with UL, CSA and International conventions.
Conduit Hub:
Zinc, Watertight
Short Circuit Withstand:
Suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical amperes at the voltage rating of the receptacle.
Assembly Screws:
Stainless Steel (300 series)
Fuse Types:
UL Listed Class J", CSA Certified HRCI-J"
Certification:
UL Listed, CSA Certified
Max Working Voltage:
600V AC RMS
Flammability:
UL94-5VA and V-0 classification.
Horsepower Rating:
705
Impact Resistance:
In accordance with UL746C
Poles and Wires:
3 Pole, 4 Wire
Service Style:
Standard
Shaft Seal:
Neoprene
Dielectric Withstand Voltage:
Withstands 3,000V AC
Amperage:
60A
Hinge Spring:
Stainless Steel (300 series)
Enclosure Hinge Pins:
Nickel Plated Brass
Package Quantity:
1
