Mechanical Conn, 500 kcmil to 4/0 AWG - KA34

Mechanical Conn, 500 kcmil to 4/0 AWG - KA34

Burndy
SKU:
KA34
|
UPC:
781810554319
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Mechanical Connector, For Conductor Material Copper, For Stranded Copper Wire Size - Minimum 4/0 AWG, For Stranded Copper Wire Size - Maximum 500 kcmil, For Stud Size 1/2 in, Head Style Hex, Number of Holes 1, Hole Diameter 0.56 in, Hole Spacing Not Applicable, Body Material Copper, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Conductors 1, Number of Terminations 1, Tongue Length Not Applicable, Tongue Width 1.38 in, Tongue Thickness 0.28 in
Additional Information
Country of Origin:
United States
Item:
Mechanical Connector
Connector Type:
Terminal
No. of Conductors:
1
Min. Conductor Size:
4/0 AWG Stranded
Max. Conductor Size:
500 kcmil Stranded
Stud Size:
1/2 in
Material:
Copper
Length:
2.55 in
Width:
2.09 in
Standards:
UL Listed
Body Material:
Copper
Head Style:
Hex
Length (Straight Wireway):
2.55 in
Maximum Operating Temperature:
194 Degrees F
For Stranded Copper Wire Size - Minimum:
4/0 AWG
Tongue Length:
Not Applicable
Overall Length:
2.55 in
Connection Orientation:
Compact
Overall Width:
2.09 in
Tongue Thickness:
0.28 in
Number of Terminations:
1
For Stranded Copper Wire Size - Maximum:
500 kcmil
Torque:
375 in-lb
Compatible with Product Type:
Copper Cable
Hole Spacing:
Not Applicable
Special Features:
Economical, Joining A Wide Range Of Cable
For Stud Size:
1/2 in
Hole Diameter:
0.56 in
Maximum Voltage:
600 V
Overall Depth:
1 3/8 in
Tongue Width:
1.38 in
For Conductor Material:
Copper
Number of Conductors:
1
Conductor Size:
4/0 AWG-500 KCMIL
Type:
Bolted Lugs & Terminals
Dimension - Bolt Size fraction:
1 to 2
Dimension - L Length Overall mm:
65 mm
Dimension - Stud Size inch:
44928
Dimension - Hole Size inch:
0.56 in
Dimension - Hole Size mm:
14 mm
Physical Attribute - Number of Screws:
1
Physical Attribute - Number of Holes:
1
Dimension - Pad Width inch:
1.38 in
Hardware Type:
13 /16 ";Dimension - Length Overall inch=2.55 in"
Dimension - Height fraction:
11722
UL Listed:
Yes
Conductor Type:
CU C Str-Size
Conductor - Copper Str Size Range:
4/0 Str. - 500 Kcmil
Standards - Industry Standards Met:
UL468A-468B
Dimension - Mounting Hardware Bolt Size inch:
13/16 in
Dimension - N inch:
0.56 in
Conductor - Copper Str Size:
4/0 AWG;250 kcmil;300 kcmil;350 kcmil;400 kcmil;450 kcmil;500 kcmil
Dimension - Height inch:
2.09 in
Certification - CSA Approved:
No
Dimension - B Length fraction:
1-3/25 in
Industry Standard(s):
UL468A-468B
Dimension - Hole Size fraction:
45185
Temperature Rating:
194
Application:
For Joining A Wide Range Of Copper Cable To Equipment Pads Or Terminal Blocks
Physical Attribute - Screw Type:
Allen
Dimension - B Length inch:
1.12 in
Installation Torque Recommended in-lb:
375 LBS/in
Package Quantity:
1
