Manual, Single Hole Only Mount, Commercial 1 Hole Glass Filler - 334-ABCP

Manual, Single Hole Only Mount, Commercial 1 Hole Glass Filler - 334-ABCP

Chicago Faucet
SKU:
334-ABCP
|
UPC:
611943476984
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Item Glass Filler
Additional Information
Country of Origin:
United States
Number of Holes:
1
Mounting Hole Center to Center:
Single Hole Only
Finish:
Polished Chrome
Number of Handles:
1
Faucet Operation:
Manual
ADA Compliant:
Yes
Flow Rate:
6.00 gpm
Handle Type:
Lever Handle
Mounting Type:
Wall Mount
Spout Length:
12";Mounting=Wall"
Connection:
1/2 MNPS"
Replacement Cartridge:
5VTV5
Flow Outlet Type (Faucet):
Aerated
Standards:
AB1953, ASME A112.18.1/CSA B125.1, NSF 61/9, ANSI A117.1, NSF 372
Drain Type:
Without Drain
Mounting Type - Faucet:
Wall
Vandal Resistant Features:
Vandal Resistant Handles
Flow Outlet Type:
Aerated
Faucet Spout:
Swing
Faucet Type:
Glass Filler
Faucet Finish:
Chrome
Compliance:
ASME A112.18.1M, CSA B125.1, California Health and Safety Code 116875 (AB 1953-2006), Vermont Bill S.152, NSF/ANSI 372 Low Lead Content Certified to NSF/ANSI 61, Section 9 by CSA, ADA ANSI/ICC A117.1
Mounting Type (Faucet):
Wall
Height:
5-3/8";Flow Outlet Type - Faucet=Aerated"
Valve Type:
Quaturn
Connection Size:
1/2 NPSM"
ADA Compliance:
Yes
Body Material:
Cast Brass
Item:
Glass Filler
Manufacturers Warranty Length:
Lifetime Warranty Metal Cast, Forged, Stamped of Formed Portion, 1 yr. Limited Finish warranty, 5 yr. Limited Cartridge Warranty
Overall Height:
5 3/8 in
Handle Material:
Metal
Residential / Commercial:
Commercial
Includes:
Mounting hardware
Type:
One Handle
Features:
Mounting Hardware Included
Water Inlet Connection Type:
Male NPSM
Faucet Body Material:
Cast Brass
Faucet Handle Material:
Metal
Max. Mounting Hole Center Distance:
Single Hole
Water Inlet Connection Size:
1/2";Ligature Resistant=No"
Spout Height:
5-3/8";Series=334"
Temperature Control:
No
Valve Type - Faucets:
Cold Cartridge
CEC Compliant:
Non CEC Compliant
Spout Reach:
12";Faucet Activation=Manual"
Max. Installation Surface Thickness:
3/8";Material of Construction=Low Lead Cast Brass"
Application:
Commercial
Outlet Type:
Aerator
Inlet Connection Type:
NPSM
Mounting Hole Center-to-Center Distance - Minimum:
Not Applicable
Inlet Connection Size:
1/2 in
Spout Outlet Height:
3 3/8 in
Compatible Cartridge Manufacturer Part Number:
5VTV5
Spout Shape:
Arc
Temperature - Maximum:
140 Degrees F
Product Type:
Glass Filler
Temperature - Minimum:
40 Degrees F
Legend Text:
Not Applicable
For Water Temperature:
Cold
Number of Mounting Holes:
1
Spout Height - Maximum:
5 3/8 in
Legend Style:
Color
Pressure - Maximum:
125 psi
Flow Type:
Aerated
For Mounting Hole Diameter - Maximum:
1/2 in
Warranty:
1 yr Limited, 5 yr Limited, Lifetime Limited
For Mounting Hole Diameter - Minimum:
Not Applicable
CEC Compliance:
Not CEC Compliant
Operation Method:
Manual
For Surface Thickness - Maximum:
3/8 in
Vandal Resistance:
Vandal Resistant Handle
Ligature Resistance:
Non-Ligature Resistant
Inlet Connection Gender:
Male
Flow Rate - Maximum:
6 gpm
Package Quantity:
1
