Manual, Single Hole Only Mount, Commercial 1 Hole Glass Filler - 312-ABCP

Manual, Single Hole Only Mount, Commercial 1 Hole Glass Filler - 312-ABCP

Chicago Faucet
SKU:
312-ABCP
|
UPC:
611943537807
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Item Glass Filler
Additional Information
Country of Origin:
Taiwan, Province of China
Number of Holes:
1
Mounting Hole Center to Center:
Single Hole Only
Finish:
Polished Chrome
Number of Handles:
1
Faucet Operation:
Manual
ADA Compliant:
Yes
Flow Rate:
1.00 gpm
Handle Type:
Metal Handle
Mounting Type:
Wall Mount
Item:
Glass Filler
Body Material:
Brass
Faucet Type:
Glass Filler
Mounting:
Wall
Valve Type:
Piston
Faucet Spout:
Rigid
Connection Size:
3/8 MNPT"
Compliance:
ASME A112.18.1M, CSA B125.1, California Health and Safety Code 116875 (AB 1953-2006), Vermont Bill S.152, NSF/ANSI 372 Low Lead Content Certified to NSF/ANSI 61, Section 9 by CSA, ADA ANSI/ICC A117.1
Mounting Type - Faucet:
Wall
Spout Length:
4-3/8";Faucet Finish=Chrome"
Flow Outlet Type:
Full Flow
Manufacturers Warranty Length:
Lifetime Warranty Metal Cast, Forged, Stamped of Formed Portion, 1 yr. Limited Finish warranty, 5 yr. Limited Cartridge Warranty
Mounting Type (Faucet):
Wall
ADA Compliance:
Yes
Standards:
AB1953, ASME A112.18.1/CSA B125.1, NSF 61/9, ANSI A117.1, NSF 372
Connection:
3/8 MNPT"
Residential / Commercial:
Commercial
Features:
Mounting Hardware Included
Includes:
Mounting hardware
Type:
Manual
Flow Outlet Type (Faucet):
Laminar
Overall Height:
4 7/8 in
Handle Material:
Metal
Replacement Cartridge Mfr. Model Number:
671-XJKABNF
Temperature Control:
No
Faucet Body Material:
Cast Brass
Spout Height:
1-1/2";Vandal Resistant Features=Vandal Resistant Handles"
Flow Outlet Type - Faucet:
Laminar
Max. Mounting Hole Center Distance:
Single Hole
Spout Reach:
4";CEC Compliant=Non CEC Compliant"
Faucet Activation:
Manual
Ligature Resistant:
No
Water Inlet Connection Type:
Male NPT
Water Inlet Connection Size:
3/8";Max. Installation Surface Thickness=1/16""
Series:
312
Valve Type - Faucets:
Cold Cartridge
Faucet Handle Material:
Metal
Overall Width:
4 3/8 in
Material of Construction:
Brass
Application:
Commercial
Outlet Type:
Full Flow
Flow Rate - Maximum:
1 gpm
Inlet Connection Gender:
Male
CEC Compliance:
Not CEC Compliant
Vandal Resistance:
Vandal Resistant Handle
For Surface Thickness - Maximum:
1/16 in
Temperature - Maximum:
140 Degrees F
Temperature - Minimum:
40 Degrees F
Inlet Connection Type:
NPT
For Mounting Hole Diameter - Maximum:
3/8 in
Ligature Resistance:
Non-Ligature Resistant
Spout Shape:
Straight
Spout Height - Maximum:
1 1/2 in
Inlet Connection Size:
3/8 in
Number of Mounting Holes:
1
Flow Type:
Laminar
Mounting Hole Center-to-Center Distance - Minimum:
Not Applicable
Compatible Cartridge Manufacturer Part Number:
671-XJKABNF
Pressure - Maximum:
125 psi
Operation Method:
Manual
For Mounting Hole Diameter - Minimum:
Not Applicable
For Water Temperature:
Cold
Warranty:
1 yr Limited, 5 yr Limited, Lifetime Limited
Product Type:
Glass Filler
Package Quantity:
1
