Manual Motor Starter, NEMA, 600VAC, 3P - 2510MCG3

Manual Motor Starter, NEMA, 600VAC, 3P - 2510MCG3

Square D
SKU:
2510MCG3
|
UPC:
785901792109
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Manual Motor Starter, NEMA Size M-1, Maximum Voltage Rating 600V AC, Number of Poles 3, Operator Push Button, Phase Three, Current AC 30 A, Horsepower @ Three Phase - 240V AC 7 1/2 hp, Horsepower @ Three Phase - 480V AC 10 hp, Series Class 2510 M Series, Horsepower @ Three Phase - 600V AC 10 hp, Maximum Overload Relay Current Setting Not Applicable, Minimum Overload Relay Current Setting Not Applicable, Mounting Style Surface, NEMA Enclosure Rating 1, Number of Required Thermals 3
Additional Information
Country of Origin:
Mexico
Operator:
Push Button
NEMA Size:
M-1
Enclosure NEMA Rating:
1
Depth:
3.91 in
Number of Required Thermals:
3
Frame Size:
Not Applicable
Amps AC:
30 A
Height:
8.63 in
Width:
5.0 in
Item:
Manual Motor Starter
Number of Poles:
3
HP @ 3 Phase - 480V:
10 hp
Max. Voltage:
600V AC
HP @ 3 Phase - 240V:
7 1/2 hp
Pilot Light:
No
HP @ 3 Phase - 460-575V:
10 hp
Thermal Unit Code:
N2
HP @ 3 Phase - 575V:
10 hp
Standards:
CSA LR60905, E42243 CCN NLRV, UL Listed
Description/Special Features:
Reliable Overload Protection
Phase Loss Sensitivity:
No
Product Certifications:
CSA LR60905 class 3211 05 || UL listed file E42243 CCN NLRV
Number Of Thermal Units Required:
3
Auxiliary Contact Composition:
without
Thermal Overload Type:
melting alloy
Product Or Component Type:
Manual Starter
Poles Description:
3P
Nema Degree Of Protection:
NEMA 1 painted sheet steel
Local Signalling:
no indicator
[Ue] Rated Operational Voltage:
600 V AC
Awg Gauge:
AWG 14...AWG 8 copper
Electrical Connection:
pressure wire clamp
Maximum Horse Power Rating:
7.5-7.5 hp 200...230 V AC, 3 phase || 10-10 hp 380...575 V AC, 3 phase
Control Type:
push-button
Motor Starter Type:
non reversing
Horsepower @ Three Phase - 480V AC:
10 hp
Series:
Class 2510 M Series
Current AC:
30 A
Maximum Overload Relay Current Setting:
Not Applicable
Terminal Connection Type:
Screw Clamp Terminals
Includes Pilot Light:
No
Overload Protection Type:
Thermal
Horsepower @ Three Phase - 600V AC:
10 hp
Maximum Voltage Rating:
600V AC
Mounting Style:
Surface
Overall Depth:
4.13 in
Starter Style:
NEMA
NEMA Enclosure Rating:
1
IP Rating:
Not Applicable
Overall Width:
5 in
Overall Height:
8.63 in
Status Indicator:
No Indicator
Horsepower @ Three Phase - 240V AC:
7 1/2 hp
Phase:
Three
Minimum Overload Relay Current Setting:
Not Applicable
Package Quantity:
1
