Male Connector, 6mm Tube Size, Nylon, Black, 10 PK - 3101 06 13

Name: Male Connector, 6mm Tube Size, Nylon, Black, 10 PK - 3101 06 13
Brand: Legris
SKU: 3101 06 13
Price: 64.27 USD
Availability: InStock

Legris

SKU:

3101 06 13

UPC:

820099206011

Availability:

In Stock

(No reviews yet)

Male Connector, Application Air, Cutting Fluids, Inert Gases, Vacuum, Fitting Side A Connection Type Push-to-Connect, Fitting Side B Connection Type MBSPP, Fitting Side B Pipe Size 1/4 in, Fitting Side A Tube Outer Diameter 6 mm, Fitting Material Nylon, Fitting Thread Size 1/4, Color Black, Includes Pre-Applied Thread Sealant No, Maximum Operating Pressure 290 psi, Maximum Operating Temperature 175 Degrees F, Overall Length 12 1/2 mm, Specific Fitting Shape Straight Adapter, Release Type Button

Country of Origin:: France
Item:: Male Connector
Specific Fitting Shape:: Straight Adapter
Tube Size:: 6mm
Pipe Size - Pipe Fitting:: 1/4 in
Max. Pressure:: 290 psi
Basic Pipe Fitting Material:: Metal
Temp. Range:: -4 Degrees to 175 Degrees F
Pipe Size (Fittings):: 1/4";Basic Material=Metal"
Hex Size:: 16 mm
Basic Pipe Fitting Shape:: Connector
Connection Type:: Push-to-Connect x MBSPP
Pipe Size:: 1/4 in
Specific Pipe Fitting Shape:: Connector
Fittings Sub-Category:: Adapters
Pipe Fitting Connection Type:: Tube x Male BSPP
Body Material:: Nickel Plated Brass
Standards:: 2011/65/EC, DI
System of Measurement:: Imperial/Metric
Application:: Air, Cutting Fluids, Inert Gases, Vacuum
Overall Length:: 12 1/2 mm
Color:: Black
Compatible Tube Material:: Fluoropolymer, Nylon, Polyethylene, Polyurethane, Semi-Rigid Nylon
Compatible Tube Hardness:: 95 Shore A
Fitting Side B Connection Type:: MBSPP
Includes Pre-Applied Thread Sealant:: No
Maximum Operating Pressure:: 290 psi
Release Type:: Button
Fitting Side A Tube Outer Diameter:: 6 mm
Maximum Operating Temperature:: 175 Degrees F
Fitting Side A Connection Type:: Push-to-Connect
Resistance Properties:: Chemical-Resistant, Corrosion-Resistant
Minimum Operating Temperature:: 4 Degrees F
Fitting Material:: Nylon
Fitting Side B Pipe Size:: 1/4 in
Vacuum Rating:: 28 inHg
Fitting Thread Size:: 1/4
Package Quantity:: 10
