Male Connector, 1/2 in Tube Size, Nylon, Black, 10 PK - 3175 62 17

Male Connector, 1/2 in Tube Size, Nylon, Black, 10 PK - 3175 62 17

Legris
SKU:
3175 62 17
|
UPC:
820099248592
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Male Connector, Application Air, Cutting Fluids, Inert Gases, Vacuum, Fitting Side A Connection Type Push-to-Connect, Fitting Side B Connection Type MBSPT, Fitting Side B Pipe Size 3/8 in, Fitting Side A Tube Outer Diameter 1/2 in, Fitting Material Nylon, Fitting Thread Size 3/8, Color Black, Includes Pre-Applied Thread Sealant Yes, Maximum Operating Pressure 290 psi, Maximum Operating Temperature 175 Degrees F, Overall Length 1 1/32 in, Specific Fitting Shape Straight Adapter
Additional Information
Country of Origin:
Mexico
Item:
Male Connector
Specific Fitting Shape:
Straight Adapter
Tube Size:
1/2 in
Pipe Size - Pipe Fitting:
3/8 in
Max. Pressure:
290 psi
Color:
Black
Body Material:
Glass Filled Nylon and Nickel Plated Brass
Pipe Size:
3/8 in
Special Features:
With Thread Sealant
Fittings Sub-Category:
Adapters
Temp. Range:
-4 Degrees to 175 Degrees F
Basic Material:
Plastic/Metal Combination
Hex Size:
22 mm
Connection Type:
Push-to-Connect x MBSPT
Overall Length:
1 1/32 in
Standards:
2011/65/EC, DI
Application:
Air, Cutting Fluids, Inert Gases, Vacuum
System of Measurement:
Imperial
Fitting Material:
Nylon
Release Type:
Button
Fitting Side A Connection Type:
Push-to-Connect
Resistance Properties:
Chemical-Resistant, Corrosion-Resistant
Fitting Side B Pipe Size:
3/8 in
Fitting Side B Connection Type:
MBSPT
Includes Pre-Applied Thread Sealant:
Yes
Vacuum Rating:
28 inHg
Fitting Side A Tube Outer Diameter:
1/2 in
Fitting Thread Size:
3/8
Maximum Operating Pressure:
290 psi
Compatible Tube Hardness:
95 Shore A
Maximum Operating Temperature:
175 Degrees F
Minimum Operating Temperature:
4 Degrees F
Compatible Tube Material:
Fluoropolymer, Nylon, Polyethylene, Polyurethane, Semi-Rigid Nylon
Package Quantity:
10
