Locking Connector, 30 A, 480V AC, 3 Pole, 3 Phase, 4 Wire, L16-30R, 16 AWG to 8 AWG, Screw Terminals - HBL2733

Locking Connector, 30 A, 480V AC, 3 Pole, 3 Phase, 4 Wire, L16-30R, 16 AWG to 8 AWG, Screw Terminals - HBL2733

Hubbell
SKU:
HBL2733
|
UPC:
783585039336
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Locking Connector, Connection Orientation Straight, Current Rating 30 A, Housing Color Black, White, Housing Material Nylon, IP Rating IP20, NEMA Receptacle Configuration L16-30R, Number of Poles 3, Number of Wires 4, Phase Three, Resistance Properties Chemical Resistant, Impact Resistant, Shrouded No, Voltage Rating 480V AC, Wire Connection Type Screw Terminals, Wiring Style Standard, Cap Type No Cap or Cover, Contact Material Brass, For Maximum Cable Diameter 1.15 in
Additional Information
Country of Origin:
United States
Item:
Locking Connector
Amps - Plugs and Receptacles:
30
NEMA Plug Configuration - Plugs and Receptacles:
L16-30R
Voltage:
480VAC
Number of Poles:
3
NEMA Configuration:
L16-30
Number of Wires:
4
Wiring Style:
Standard
Flange Material:
Nylon
Color:
Black/White
Grade - Plugs and Receptacles:
Industrial
Shrouded / Non-Shrouded:
Non-Shrouded
Cord Size:
0.350 in to 1.150 in
Grade:
Industrial/Commercial
Phase:
Three
Boot Code:
C
Color - Plugs and Receptacles:
Black/White
HP:
10.0
Corrosion Resistant:
No
Item - Plugs and Receptacles:
Locking Connector
IP Rating:
IP20
Material:
Nylon
Power Indicator:
No
Standards:
CSA Certified C22.2 No. 42, Federal Specification W-C-596, UL 498
Voltage - Plugs and Receptacles:
480V AC
Amps:
30
Antimicrobial:
No
Body Material:
Natural White Nylon
Special Features:
Terminals identified in accordance with UL 498
Wire Connection Type:
Screw Terminals
Power Indicating Light:
No
Housing Color:
Black, White
Outside Diameter:
2.33 in
Shrouded:
No
Connection Orientation:
Straight
UL 94 Flammability Rating:
HB
Midget Locking:
No
Grounding:
Grounded
Maximum Wire Size:
8 AWG
Voltage Rating:
480V AC
Contact Material:
Brass
NEMA Receptacle Configuration:
L16-30R
Cap Type:
No Cap or Cover
Current Rating:
30 A
Market:
Industrial
Resistance Properties:
Chemical Resistant, Impact Resistant
For Location:
Indoor
Horsepower Rating:
10 hp
Maximum Operating Temperature:
75 Degrees C
Housing Material:
Nylon
Overall Length:
2.33 in
For Minimum Cable Diameter:
0.35 in
Minimum Wire Size:
16 AWG
Minimum Operating Temperature:
-40 Degrees C
For Maximum Cable Diameter:
1.15 in
For Environment:
Dry
Temp. Rise:
Max 30C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of .75.
Weight:
3.05
Flame Resistant:
HB or better per UL94 or CSA 22.2 No. 0.6
Dielectric Strength:
Withstands 2,000V minimum
Cord Dia. Range:
.350-1.150" (9-29)"
Package Quantity:
1
