Limit Switch, Wobble Stick, 1NC/1NO, 4A @ 400V AC, Actuator Location: Top - LS-S11S-S

Limit Switch, Wobble Stick, 1NC/1NO, 4A @ 400V AC, Actuator Location: Top - LS-S11S-S

Eaton
SKU:
LS-S11S-S
|
UPC:
786685392691
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Coil Spring Limit Switch, Actuator Style - Limit Switch Wobble Stick, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 4A @ 400V, DC Contact Rating - Limit Switch Not Rated, Contact Form- Switches 1NC/1NO, Actuator Length - Limit Switch 4.96 in, Body Height - Limit Switch 2.53 in, Body Width - Limit Switch 1.22 in, Body Depth - Limit Switch 1.32 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 3, 3S, 4X, 6P
Additional Information
Country of Origin:
Germany
Item:
Limit Switch
Basic Actuator Style - Limit Switch:
Wobble Stick
Actuator Style - Limit Switch:
Wobble Stick
Contact Form- Switches:
1NC/1NO
Actuator Location - Limit Switch:
Top
AC Contact Rating - Limit Switch:
4A @ 400V
DC Contact Rating - Limit Switch:
Not Rated
Body Style - Limit Switch:
Miniature
Mounting - Limit Switch:
Surface
Stem Thread - Limit Switch:
No Stem
Mounting Hole Pattern - Limit Switch:
2 Hole Horizontal
Operating Temp. Range:
-13 Degrees to 158 Degrees F
Basic Actuator Style (Limit Switch):
Wobble Stick
Electrical Connection:
Screw Terminals
Series:
LS
Limit Switch Style:
General Purpose Limit Switch
Actuator Location:
Top
Actuator Length - Limit Switch:
4.96 in
Mounting Hole - Limit Switch:
(2) 0.16 in dia
Actuator Style:
Wobble Stick
Voltage Rating:
400VAC
Actuator Length:
4.96";Body Width - Limit Switch=1.22 in"
Amps:
4
Body Height - Limit Switch:
2.53 in
Wiring Entry:
M20 Thread
Depth:
1.32";Contact Form=1NC/1NO"
Operating Force:
0.2 N-m
NEMA Rating:
3, 3S, 4X, 6P
Body Depth - Limit Switch:
1.32 in
Travel:
Operating Travel 43 Degrees , Reset Travel 22 Degrees , Total Travel 65 Degrees
Contact Form - Limit Switch:
1NC/1NO
Width:
1.22";DC Contact Rating=Not Rated"
Body Style (Limit Switch):
Miniature
Actuator Style (Limit Switch):
Wobble Stick
IP Rating:
67
Movement:
Horizontal
Mounting Hole Spacing - Limit Switch:
0.87 in
Boot Sealed Actuator (Limit Switch):
No
Height:
2.99";Boot Sealed Actuator - Limit Switch=No"
Standards:
CCC, CE, CSA, UL LISTED
Actuator Location (Limit Switch):
Top
AC Contact Rating:
4A @ 400V
Connection Type:
Screw terminal
Arm Width:
0.23 in
Differential Travel:
26 Degrees
Certification:
UL Listed
Roller Width:
Not Applicable
Body Material:
Plastic
Arm Material:
Polymer
Weight:
.15 lb
Operating Temperature - Max:
158 °F
Environmental Rating:
IP66, IP67
Actuator:
Spring rod (wobble)
Type:
LS-Titan
Product Length/Depth:
2.99 in
Contact Configuration:
1 NO-1 NC with positive opening contact
Enclosure Material:
Plastic
Maximum DC Current:
3 A at 24 Vdc
Accuracy:
±0.02mm
Contact Rating:
6A at 230 Vac, 3A at 24 Vdc
Product Name:
Eaton LS-Titan miniature DIN limit switch
Maximum AC Current:
6 A at 230 Vac
Operating Temperature - Min:
-13 °F
Body Configuration:
Plug-In
Operating Temperature - Maximum:
158 Degrees F
Operating Torque - Maximum:
1.77 in-lb
Mounting Hole Horizontal Center to Center Distance:
22 mm
Mounting Hole Diameter:
0.16 in
Mounting Hole Vertical Center to Center Distance:
43 mm
Body Depth:
1.32 in
Overall Width:
1.22 in
Operating Force - Maximum:
8 N
Arm Length - Maximum:
Not Applicable
Boot Sealed Actuator:
No Boot Included
NEMA Enclosure Rating:
3, 3S, 4X, 6P
Plunger Adjustability:
Fixed
Action:
Momentary/Momentary
Reset Travel:
3 Degrees
Wireless Network Interface:
Not Applicable
Body Width:
1.22 in
Pretravel:
20 Degrees
Mounting Style:
Surface
Number of Mounting Holes:
2
Directional Movement:
Omnidirectional
Body Height:
2.53 in
Operating Force - Minimum:
1 N
Total Travel:
65 Degrees
Roller Position:
Top
Arm Adjustability:
Fixed
Operating Temperature - Minimum:
-13 Degrees F
Includes Actuator:
Actuator Included
Lamp Type:
No Lamp Module Included
Overall Height:
1.32 in
Arm Length - Minimum:
Not Applicable
Manufacturer Warranty Length:
1 yr
Overall Depth:
2.99 in
Package Quantity:
1
