Limit Switch, Wobble Stick, 1NC/1NO, 10A @ 240V AC, Actuator Location: Top - XCKL106H7

Limit Switch, Wobble Stick, 1NC/1NO, 10A @ 240V AC, Actuator Location: Top - XCKL106H7

Telemecanique Sensors
SKU:
XCKL106H7
|
UPC:
785901451624
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Limit Switch, Actuator Style - Limit Switch Wobble Stick, Actuator Location - Limit Switch Top, AC Contact Rating - Limit Switch 10A @ 240V, DC Contact Rating - Limit Switch 10A @ 240V, Contact Form- Switches 1NC/1NO, Actuator Length - Limit Switch 5.61 in, Body Height - Limit Switch 2.83 in, Body Width - Limit Switch 2.04 in, Body Depth - Limit Switch 1.18 in, Boot Sealed Actuator - Limit Switch No, Body Style - Limit Switch Miniature, NEMA Rating 1, 12, 2, 3, 4, Mounting - Limit Switch Surface
Additional Information
Country of Origin:
France
Item:
Limit Switch
Basic Actuator Style - Limit Switch:
Wobble Stick
Actuator Style - Limit Switch:
Wobble Stick
Contact Form- Switches:
1NC/1NO
Actuator Location - Limit Switch:
Top
AC Contact Rating - Limit Switch:
10A @ 240V
DC Contact Rating - Limit Switch:
10A @ 240V
Body Style - Limit Switch:
Miniature
Mounting - Limit Switch:
Surface
Arm Material:
Steel
Wiring Entry:
1/2 in NPT
Body Depth - Limit Switch:
1.18 in
Amps:
10
Limit Switch Style:
General Purpose Limit Switch
Arm Width:
0.05 in
Body Height - Limit Switch:
2.83 in
Electrical Connection:
Screw Terminals
Standards:
CE, CSA, UL
DC Contact Rating:
10A @ 240V
Voltage Rating:
240VAC/DC
Actuator Length:
5.61";Contact Form - Limit Switch=1NC/1NO"
Width:
2.04";Body Width - Limit Switch=2.04 in"
Body Style (Limit Switch):
Miniature
AC Contact Rating:
10A @ 240V
IP Rating:
66
Movement:
Any Direction
Height:
2.83";Mounting Hole Pattern - Limit Switch=2 Hole Horizontal"
Depth:
1.18";Travel=Total Travel 300 Degrees"
Contact Form:
1NC/1NO
Stem Thread - Limit Switch:
No Stem
Actuator Length - Limit Switch:
5.61 in
Actuator Location:
Top
Boot Sealed Actuator - Limit Switch:
No
Basic Actuator Style (Limit Switch):
Wobble Stick
Mounting Hole - Limit Switch:
(2) 0.20 in dia
Series:
XCKL
Boot Sealed Actuator (Limit Switch):
No
Mounting Hole Spacing - Limit Switch:
1.61 in
Operating Temp. Range:
-13 Degrees to 158 Degrees F
Actuator Location (Limit Switch):
Top
Actuator Style (Limit Switch):
Wobble Stick
Operating Force:
1.15 in-lb
NEMA Rating:
1, 12, 2, 3, 4
Actuator Style:
Wobble Stick
Body Material:
Zinc
Special Features:
multi-directional approach
Certification:
CSA || UL
Vibration Resistance:
25 gn 10-500 Hz)EN/IEC 60068-2-6
Short Circuit Protection:
10 A cartridge fuse gG
Actuation Type:
by any moving part
Shock Resistance:
50 gn 11 ms EN/IEC 60068-2-27
Min. Actuation Velocity Horizontal:
1 m/s
Contact Action:
snap action
Electrical Durability:
5000000 cycles, DC-13, inductive, 120 V, 4 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13, inductive, 24 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13, inductive, 48 V, 10 W 60 cyc/mn 0.5 IEC 60947-5-1 appe
Head Type:
multi-directional head
Mechanical Durability:
10000000 cycles
Type Of Operator:
spring return cat''s whisker
Number Of Poles:
2
Mounting Hole Diameter:
0.2 in
Overall Width:
2.05 in
Body Height:
2.83 in
Total Travel:
300 Degrees
Manufacturer Warranty Length:
18 mo
Operating Temperature - Maximum:
158 Degrees F
Operating Torque - Minimum:
Not Applicable
Operating Temperature - Minimum:
-13 Degrees F
Overall Height:
2.83 in
Arm Length - Maximum:
Not Applicable
Resistance Properties:
Shock Resistant, Vibration Resistant
Directional Movement:
Omnidirectional
Body Depth:
1.18 in
NEMA Enclosure Rating:
1, 12, 2, 3, 4
Arm Length - Minimum:
Not Applicable
Body Width:
2.05 in
Number of Mounting Holes:
2
Mounting Hole Horizontal Center to Center Distance:
41 mm
Operating Torque - Maximum:
1.15 in-lb
Mounting Style:
Surface
Wireless Network Interface:
Not Applicable
Overall Depth:
1.18 in
Boot Sealed Actuator:
No Boot Included
Package Quantity:
1
