LED Light Fixture, Haz Location, Srfc Mnt - VM1L4530

LED Light Fixture, Haz Location, Srfc Mnt - VM1L4530

Killark
SKU:
VM1L4530
|
UPC:
783936072814
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
LED Light Fixture, Lighting Technology LED, Lumens 3,813 lm, Overall Height 7 1/2 in, Overall Length 13 1/2 in, Overall Width 13 5/8 in, Safety Rating Class I, Division 2, Group A, B, C, D, Class I, Zone 2 AEx nAnR, Class I, Zone 2 Ex nR, Class II, Divisions 1 and 2, Group E, F, G, Class III, Class l, Group IIC, Group llB, Group llA, Zone 2, Color Temperature 5000K, Emergency Battery Backup No, 120 to 277V AC, Dimmable No, Ambient Temp. Range -40 Degrees to 131 Degrees F
Additional Information
Country of Origin:
United States
Item:
LED Light Fixture
Fixture Type:
Hazardous Location
LED Replacement For:
150W HPS/100W MH
Fixture Wattage:
45
Lamp Watts:
45
Lamp Type:
LED
Ambient Temp. Range:
-40 Degrees to 131 Degrees F
Voltage:
120 to 277V AC
Lamp Included:
Yes
Mounting:
Surface
Finish:
Baked Powder Epoxy/Ppolyester
Length:
13 1/2 in
Height:
7 1/2 in
Housing Finish:
Baked Powder Epoxy
Nominal Height:
7 1/2 in
Light Color:
Cool White
Fixture Warranty:
5 yr.
Fixture Type - Decorative and Surface Mount Fixtures:
Hazardous Location Pendant
Nominal Length:
13 1/2 in
Lamp Watts - Fixtures:
45 W
Fixture Housing Color:
Tan
Item - Decorative and Surface Mount Fixtures:
LED Surface Mount Fixture
Number of Light Bars:
0
Fixture Rated Life:
60,100 hr.
Lighting Technology:
LED
Width:
13 5/8 in
Fixture Temp. Range:
-40 Degrees to 55 Degrees C
Fixture Voltage:
120 to 277V AC
Linkable Up To:
Unlinkable
Dimmable:
No
Emergency Battery Backup:
No
Housing Material:
Aluminum
Nominal Width:
13 5/8 in
IP Rating:
IP66
Lamp Quantity:
10
Lumens Per Watt:
64.0
Color Temperature:
5000K
Max. Fixture Wattage:
45 W
Lumens:
3,813 lm
Standards:
NEMA 4, NEMA 3
Fixture Housing Material:
Aluminum
Color Rendering Index:
70.0
Description/Special Features:
Surface Mount
Lumens per Watt:
45 lm/W
Overall Width:
13 5/8 in
Max. Ambient Temp.:
131 Degrees F
Overall Height:
7 1/2 in
Mounting Style:
Pendant
For Bulb Type:
LED
Temperature Code:
T4A
Hazardous Class:
Class I/Division 2, Class II/Division 1, Class II/Division 2, Class III
Min. Ambient Temp.:
-40 Degrees F
For Max. Bulb Wattage:
45 W
Safety Rating:
Class I, Division 2, Group A, B, C, D, Class I, Zone 2 AEx nAnR, Class I, Zone 2 Ex nR, Class II, Divisions 1 and 2, Group E, F, G, Class III, Class l, Group IIC, Group llB, Group llA, Zone 2
Ingress Protection Rating:
66
CA Title 24 Compliant:
No
Shape:
Circular
Housing Color:
Tan
Overall Length:
13 1/2 in
Series:
VM1
Mounting Location:
Pendant, Surface
Package Quantity:
1
