Keyless Bushing, Shaft Dia. 2.0000 In - 6202560UP

Keyless Bushing, Shaft Dia. 2.0000 In - 6202560UP

Fenner Drives
SKU:
6202560UP
|
UPC:
662345121088
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Keyless Bushing, Flange Type None, For Bore Diameter 2 in, Keyless Bushing Type Single Nut Locking Assembly, Material Steel, Outside Diameter 2 7/8 in, Overall Width 3.563 in, System of Measurement Inch, Finish Oil Dipped, Hub Contact Pressure 4,200 psi, Maximum Transmitted Torque 1,167 ft-lb, Outside Diameter Tolerance +/-0.003
Additional Information
Country of Origin:
United States
Item:
Keyless Bushing
Keyless Bushing Type:
Single Nut Locking Assembly
Keyless Bushing Series:
GT
For Shaft Dia. - Bushings:
2 in
Outside Dia. (In.):
2.8750
Overall Length:
3.563 in
Material - Bushings:
Steel
Transmissible Torque:
1,167 ft-lb
Withstand Temp. (Deg. F):
Up to 400 Degrees F
Transmissible Thrust (Lbs.):
15,000
Material:
Steel
Transmissible Torque (Ft.-Lbs.):
1167
Outside Dia.:
2.875 in
Hub Contact Pressure (PSI):
4,200
Package Quantity:
1
Shaft Dia. Tolerance:
+/-0.003
Overall Length (In.):
3.5625
Shaft Dia. (In.):
2.0000
Type:
Trantorque GT
Agency Compliance:
RoHS
Finish:
Oil Dipped
Outside Dia. Tolerance:
+/-0.003
Standards:
ROHS
Maximum Transmitted Torque:
1,167 ft-lb
Overall Width:
3.563 in
Hub Contact Pressure:
4,200 psi
Outside Diameter:
2 7/8 in
Outside Diameter Tolerance:
+/-0.003
System of Measurement:
Inch
For Bore Diameter:
2 in
Flange Type:
None
