Joystick Operator, 22mm, 4 Dir, Maintained - XD4PA14

Joystick Operator, 22mm, 4 Dir, Maintained - XD4PA14

Schneider Electric
SKU:
XD4PA14
|
UPC:
785901376453
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Joystick Operator, 22 mm, Number of Directions 4, 1NO Contact Form, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation R300, Joystick Material Metal, Bezel Chromium Plated Metal, Latching, Vertical and Horizontal Direction of Operation, Action Maintained, NEMA Rating 13, 4X, IP Rating IP66, Standards China RoHS, EU RoHS, REACH, WEEE
Additional Information
Country of Origin:
France
Item:
Joystick Operator
Size:
22 mm
Number of Directions:
4
Contact Form:
1NO
Contact Rating:
10A @ 600V AC
Joystick Material:
Metal
Action:
Maintained
NEMA Rating:
13, 4X
Latching / Non-Latching:
Latching
Direction of Operation:
Vertical and Horizontal
IP Rating:
IP66
Bezel:
Chromium Plated Metal
Standards:
China RoHS, EU RoHS, REACH, WEEE
NEMA Contact Rating Designation:
R300
Shape Of Screw Head:
cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
Connections - Terminals:
screw clamp terminals, <= 2 x 1.5 mm² with cable end EN 60947-1 || screw clamp terminals, >= 1 x 0.22 mm² without cable end EN 60947-1
Short-Circuit Protection:
10 A cartridge fuse gG EN/IEC 60947-5-1
Bezel Material:
Metal
Electrical Reliability:
λ < 10exp(-6) 5 V, 1 mA in clean environment EN/IEC 60947-5-4 || λ < 10exp(-8) 17 V, 5 mA in clean environment EN/IEC 60947-5-4
[Ie] Rated Operational Current:
0.1 A 250 V, DC-13, R300 EN/IEC 60947-5-1 || 0.22 A 125 V, DC-13, R300 EN/IEC 60947-5-1
Resistance To High Pressure Washer:
7000000 Pa 55°C 0.1 m
Operator Direction Information:
4 directions
[Ith] Conventional Free Air Thermal Current:
10 A EN/IEC 60947-5-1
Shape Of Signaling Unit Head:
round
Mechanical Durability:
1000000 cycles
Ip Degree Of Protection:
IP66 IEC 60529
Contacts Usage:
standard
Electrical Shock Protection Class:
class I IEC 60536
Ambient Air Temperature For Operation:
-25-70°C
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Positive Opening:
without
Product Certifications:
LROS (Lloyds register of shipping) || CSA || UL Listed || BV || DNV || GL
Contact Operation:
slow-break
Notch Per Direction:
1-1
Protective Treatment:
TH
Mounting Diameter:
22 mm
Contacts Type And Composition:
1 NO
Electrical Durability:
1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C || 1000000 cycles
Type Of Operator:
stay put, long operating shaft 54 mm
Product Or Component Type:
joystick controller
Contacts Material:
silver alloy (Ag/Ni)
Nema Degree Of Protection:
NEMA 13 || NEMA 4X
Tightening Torque:
0.8-1.2 N.m EN 60947-1
Vibration Resistance:
5 gn 2-500 Hz)IEC 60068-2-6
Ambient Air Temperature For Storage:
-40-70°C
Device Short Name:
XD4
Device Presentation:
complete product
Operator Position Information:
5 positions
Fixing Collar Material:
zamak
[Ui] Rated Insulation Voltage:
600 V 3)EN 60947-1
[Uimp] Rated Impulse Withstand Voltage:
6 kV EN 60947-1
Ik Degree Of Protection:
IK03 IEC 50102
Panel Cutout Diameter:
22 mm
DC Contact Rating:
0.1 A @ 250 V, 0.22 A @ 125 V
Overall Depth:
5.24 in
Manufacturer Warranty Length:
18 mo
Number of Positions:
4
NEMA Enclosure Rating:
13, 4X
Switch Action:
Maintained
Shaft Length:
2.13 in
AC Contact Rating:
1.5 A @ 240 V, 3 A @ 120 V
Series:
XB4
Latch Type:
Latching
Overall Width:
1.18 in
Package Quantity:
1
