ISCC-100-100-KW One-Piece Industry Standard Clamping Coupling with Keyway - ISCC-100-100-KW

ISCC-100-100-KW One-Piece Industry Standard Clamping Coupling with Keyway - ISCC-100-100-KW

Climax Metal Products
SKU:
ISCC-100-100-KW
|
UPC:
44861411087
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Rigid Shaft Coupling, Bore Diameter 1 1 in, Bore Diameter 2 1 in, Bore Type Round Keyed, Clearance Diameter 2.06 in, Coupling Construction One-Piece, Coupling Material Carbon Steel, Coupling Outside Diameter 1 3/4 in, Different Bore Sizes No, Keyway Depth 1 1/8 in, Keyway Depth 2 1/8 in, Minimum Bore Diameter 1 in, Keyway Width 1 1/4 in, Keyway Width 2 1/4 in, Maximum Bore Diameter 1 in, Maximum Speed 4,000 RPM, Maximum Torque 2,470 in-lb, Overall Length 3 in, Shaft Locking Type Clamp On
Additional Information
Country of Origin:
United States
Shaft Locking Type - Couplings:
1 Piece Clamp
Item:
Rigid Shaft Coupling
System of Measurement:
Inch
Bore Dia.:
1 in
Material - Couplings:
Steel
Outside Dia.:
2 1/16 in
Overall Length:
3 in
With Keyway / Without Keyway:
With Keyway
Finish:
black oxide
Design:
(4) Socket Capscrews
Keyway Width (In.):
1/4
Clearance Dia.:
2.063 in
Application:
For Applications where Alignment is Critical, Particularly when no Backlash is Desired and Flexibility is not Required, Useful when Timing, Joining and/or Aligning Shafts at Lower Speeds and Torque
Type:
One Piece Clamp Type, with Keyway
Machined From:
Bar Stock
Material:
Steel
Screw Size (In.):
1/4-28 x 5/8
Max. RPM:
4,000 RPM
Max. Torque:
2,470 in-lb
Item - Rigid Shaft Couplings:
Rigid Shaft Coupling
Screw Size:
1/4-28"
Max. Torque (In.-Lbs.):
2470
Keyway Width:
1/4 in
Clearance Dia. (In.):
2-1/16
Standards:
Conflict Minerals and Materials Compliant, DFARS Compliant, REACH Compliant, RoHS3 Compliant
Screw Material:
Carbon Steel
Bore Tolerance:
+0.003 in / -0.000 in
Coupling Material Finish:
Black Oxide
Coupling Outside Diameter:
1 3/4 in
Included Screws:
(4) Hex Socket Cap Screws
Maximum Speed:
4,000 RPM
Bore Diameter 2:
1 in
Bore Diameter 1:
1 in
Screw Thread Size:
1/4-28"
Keyway Width 2:
1/4 in
Keyway Depth 2:
1/8 in
Coupling Construction:
One-Piece
Maximum Torque:
2,470 in-lb
Coupling Material:
Carbon Steel
Shaft Locking Type:
Clamp On
Minimum Bore Diameter:
1 in
Zero Backlash:
Yes
Keyway Width 1:
1/4 in
Screw Material Finish:
Black Oxide
Different Bore Sizes:
No
Bore Type:
Round Keyed
Clearance Diameter:
2.06 in
Keyway Depth 1:
1/8 in
Number of Locking Screws:
4
Maximum Bore Diameter:
1 in
Coupling Material Grade:
1211
Screw Material Grade:
4140
Package Quantity:
1
