ISCC-100-075 One-Piece Industry Standard Clamping Coupling - ISCC-100-075

ISCC-100-075 One-Piece Industry Standard Clamping Coupling - ISCC-100-075

Climax Metal Products
SKU:
ISCC-100-075
|
UPC:
44861411070
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Rigid Shaft Coupling, Bore Diameter 1 1 in, Bore Diameter 2 3/4 in, Bore Type Round, Clearance Diameter 2.06 in, Coupling Construction One-Piece, Coupling Material Carbon Steel, Coupling Outside Diameter 1 3/4 in, Different Bore Sizes Yes, Keyway Depth 1 Not Applicable, Keyway Depth 2 Not Applicable, Minimum Bore Diameter 3/4 in, Keyway Width 1 Not Applicable, Keyway Width 2 Not Applicable, Maximum Bore Diameter 1 in, Maximum Speed 4,000 RPM, Maximum Torque 1,850 in-lb, Overall Length 3 in
Additional Information
Country of Origin:
United States
Item:
Rigid Shaft Coupling
Shaft Locking Type - Couplings:
1 Piece Clamp
System of Measurement:
Inch
Bore Dia.:
3/4 in x 1 in
Material - Couplings:
Steel
Outside Dia.:
2 1/16 in
Overall Length:
3 in
With Keyway / Without Keyway:
Without Keyway
Finish:
black oxide
Application:
For Applications where Alignment is Critical, Particularly when no Backlash is Desired and Flexibility is not Required, Useful when Timing, Joining and/or Aligning Shafts at Lower Speeds and Torque
Material:
Steel
Max. RPM:
4,000 RPM
Item - Rigid Shaft Couplings:
Rigid Shaft Coupling
Clearance Dia. (In.):
2-1/16
Design:
(4) Socket Capscrews
Clearance Dia.:
2.063 in
Max. Torque (In.-Lbs.):
1850
Max. Torque:
1,850 in-lb
Screw Size:
1/4-28"
Type:
One Piece Clamp Type, Without Keyway
Machined From:
Bar Stock
Screw Size (In.):
1/4-28 x 5/8
Standards:
Conflict Minerals and Materials Compliant, DFARS Compliant, REACH Compliant, RoHS3 Compliant
Bore Tolerance:
+0.000 in / -0.003 in
Screw Material:
Carbon Steel
Coupling Material Grade:
1211
Coupling Construction:
One-Piece
Clearance Diameter:
2.06 in
Shaft Locking Type:
Clamp On
Keyway Depth 2:
Not Applicable
Maximum Speed:
4,000 RPM
Screw Material Finish:
Black Oxide
Keyway Width 1:
Not Applicable
Screw Thread Size:
1/4-28"
Maximum Torque:
1,850 in-lb
Screw Material Grade:
4140
Coupling Material Finish:
Black Oxide
Minimum Bore Diameter:
3/4 in
Bore Type:
Round
Number of Locking Screws:
4
Coupling Material:
Carbon Steel
Zero Backlash:
Yes
Bore Diameter 2:
3/4 in
Included Screws:
(4) Hex Socket Cap Screws
Bore Diameter 1:
1 in
Keyway Depth 1:
Not Applicable
Coupling Outside Diameter:
1 3/4 in
Different Bore Sizes:
Yes
Maximum Bore Diameter:
1 in
Keyway Width 2:
Not Applicable
Package Quantity:
1
