Illuminated Push Button, 30 mm, SPDT, Red - 9001SK1L1RH13

Illuminated Push Button, 30 mm, SPDT, Red - 9001SK1L1RH13

Schneider Electric
SKU:
9001SK1L1RH13
|
UPC:
785901040378
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Illuminated Push Button, 30 mm, Momentary Action, Round Guarded Button Type of Operator, Head Material Plastic, Contact Form SPDT, Bezel Corrosion Resistant Thermoplastic, Color Red, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/Q600, Number of Operators 1, NEMA Rating 1, 12, 13, 2, 3, 3R, 4, 4X, 6, IP Rating IP66, Legend Not Applicable, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C4520, JIS C852, REACH, RoHS, UL 508, WEEE
Additional Information
Country of Origin:
Mexico
Action:
Momentary
Size:
30 mm
Head Material:
Plastic
NEMA Rating:
1, 12, 13, 2, 3, 3R, 4, 4X, 6
Lamp Voltage:
6V AC
Lamp Type:
Incandescent
Type of Operator:
Round Guarded Button
Contact Form:
SPDT
Color:
Red
Bezel:
Corrosion Resistant Thermoplastic
Legend:
Not Applicable
Number of Operators:
1
Item:
Illuminated Push Button
Contact Rating:
10A @ 600V AC
Bezel Material:
Plastic
Lamp Module Voltage:
120V AC
Standards:
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C4520, JIS C852, REACH, RoHS, UL 508, WEEE
Basic Material:
Plastic
NEMA Contact Rating Designation:
A600/Q600
IP Rating:
IP66
Lamp Module Type:
Transformer
Contact Type:
1NO/1NC
Replacement Lamp:
Mfr. No. 755
Terminal Connection:
Screw Clamp
DC Contact Rating:
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @ 125 V
AC Contact Rating:
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
Series:
9001SK
Product Type:
Push Button Operators
Hazardous Location Specification:
Class I, Div 2, Group A, B, C, D, Class II, Div 2, Group E, F, G, Class III, Div 1 and 2
Resistance Properties:
Corrosion Resistant, Dust Resistant, Impact Resistant, Vibration Resistant, Watertight
NEMA Enclosure Rating:
1, 12, 13, 2, 3, 3R, 4, 4X
Number of Indicator Lights:
0
Operator Material:
Plastic
Lamp Voltage - Maximum:
120 V AC
Operating Temperature - Maximum:
158 Degrees F
Panel Cutout Diameter:
30 mm
Legend Background Color:
Not Applicable
Operator Voltage Rating - Maximum:
600 V AC
Maintained Action Release:
Not Applicable
Operator Illumination:
Illuminated
Head Color:
Red
Mechanical Operating Durability:
5.00 x 10^6
Manufacturer Warranty Length:
18 mo
Mushroom Head Diameter:
Not Applicable
Operating Temperature - Minimum:
-13 Degrees F
Push Button Style:
Flush
Legend Color:
Not Applicable
Ip Degree Of Protection:
IP66 IEC 60529
Contacts Type And Composition:
1 C/O
Device Short Name:
9001SK
Contact Operation:
standard
Contacts Material:
silver alloy contacts
Device Presentation:
complete product
[Ith] Conventional Free Air Thermal Current:
10 A
Ambient Air Temperature For Storage:
-40-70°C
Mounting Diameter:
30 mm
Bulb Base:
BA 9s
[Ui] Rated Insulation Voltage:
250 V 3)EN/IEC 60947-1
Shape Of Screw Head:
cross slotted
Vibration Resistance:
7 gn 2-500 Hz)IEC 60068-2-6
Connections - Terminals:
screw clamp terminals 1 x 0.22 to 2 x 1.5 mm² EN/IEC 60947-1
Light Block Supply:
via integral transformer
Voltage:
110 to 120V
Mechanical Durability:
5000000 cycles
Protective Treatment:
TC
[Uimp] Rated Impulse Withstand Voltage:
2.5 kV EN/IEC 60947-1
Ambient Air Temperature For Operation:
-25-70°C
Shock Resistance:
50 gn IEC 60068-2-27
Operating Position:
any position
Product Certifications:
UL 508 || NEMA
Rated Breaking Capacity:
1.2 kA 600 V AC-15, 720 VA || 1.5 kA 480 V AC-15, 720 VA || 3 kA 240 V AC-15, 720 VA || 6 kA 120 V AC-15, 720 VA || 0.1 kA 240 V DC-13 || 0.27 kA 250 V DC-13 || 0.55 kA 125 V DC-13
[Ie] Rated Operational Current:
3 A 240 V, AC-15, A600-Q600 NEMA
[Icm] Rated Short-Circuit Making Capacity:
0.1 kA 240 V DC-13, 7200 VA || 12 kA 600 V AC-15, 7200 VA || 15 kA 480 V AC-15, 7200 VA || 30 kA 125 V DC-13, 7200 VA || 30 kA 240 V AC-15, 7200 VA || 60 kA 120 V AC-15, 7200 VA || 60 kA 250 V DC-13, 7200 VA
Tightening Torque:
0.8-0.8 N.m EN/IEC 60947-1
[Us] Rated Supply Voltage:
110 to 120 V AC 50/60 Hz, 110 to 120 V
Nema Degree Of Protection:
NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 4X
Operator Additional Information:
plastic guard
Electrical Shock Protection Class:
class II IEC 61140
Short-Circuit Protection:
10 A cartridge fuse EN/IEC 60947-5-1
Operator Profile:
red flush, flush
Cap/Operator Or Lens Colour:
red
Product Or Component Type:
illuminated push-button
Light Source:
incandescent
Package Quantity:
1
