Illuminated Push Button, 30 mm, 1NO/1NC, Green - 52PP2D3A

Illuminated Push Button, 30 mm, 1NO/1NC, Green - 52PP2D3A

Siemens
SKU:
52PP2D3A
|
UPC:
662643314670
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Mushroom Head Push Button, 30 mm, Maintained Action, 44mm Mushroom Head Type of Operator, Head Material Metal, Contact Form 1NO/1NC, Bezel Chrome Plated Zinc Die Cast, Color Green, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/P600, Number of Operators 1, NEMA Rating 1, 12, 13, 3, 3R, 4, 4X, IP Rating IP10, IP11, IP14, IP52, IP54, IP56, IP66, Legend Not Applicable, Standards CSA, REACH, UL Listed, Terminal Connection Pressure Plate
Additional Information
Country of Origin:
Mexico
Action:
Maintained
Size:
30 mm
Head Material:
Metal
Lamp Voltage:
24V AC/DC
NEMA Rating:
1, 12, 13, 3, 3R, 4, 4X
Lamp Type:
Incandescent
Type of Operator:
44mm Mushroom Head
Color:
Green
Contact Form:
1NO/1NC
Bezel:
Chrome Plated Zinc Die Cast
Legend:
Not Applicable
Number of Operators:
1
Contact Rating:
10A @ 600V AC
Item:
Mushroom Head Push Button
Bezel Material:
Chrome
NEMA Contact Rating Designation:
A600/P600
Voltage:
24V AC/DC
Terminal Connection:
Pressure Plate
Lamp Module Type:
Full Voltage
Lamp Module Voltage:
24V AC/DC
Basic Material:
Metal
Replacement Lamp:
Mfr. No. 52AADN
Contact Type:
1NO/1NC
Standards:
CSA, REACH, UL Listed
IP Rating:
IP10, IP11, IP14, IP52, IP54, IP56, IP66
Series:
52
Features:
Bifurcated Movable Contacts, Boots Not Required, NEMA A600/P600 Contacts, Octagonal Mounting Nuts, Positive Indexing Selectors, Positively Driven Contacts, Touchsafe Terminals
AC Contact Rating:
10 A @ 600 V
DC Contact Rating:
Not Rated
Product Type:
Push Button Operators
Legend Color:
Not Applicable
Manufacturer Warranty Length:
1 yr
NEMA Enclosure Rating:
1, 12, 13, 3, 3R, 4, 4X
Operator Material:
Metal
Legend Background Color:
Not Applicable
Operating Temperature - Minimum:
31 Degrees F
Overall Width:
2.15 in
Mushroom Head Diameter:
44.45 mm
Number of Indicator Lights:
0
Push Button Style:
Mushroom Head
Hazardous Location Specification:
Class I, Div 2, Group A, B, C, D
Operator Voltage Rating - Maximum:
600 V AC
Overall Height:
4.49 in
Operating Temperature - Maximum:
158 Degrees F
Operator Illumination:
Illuminated
Head Color:
Green
Mechanical Operating Durability:
3.00 x 10^5
Lamp Voltage - Maximum:
24 V AC/DC
Panel Cutout Diameter:
30 mm
Maintained Action Release:
Push/Pull
Resistance Properties:
Oil and Grease Resistant, Watertight
Package Quantity:
1
