Illuminated Push Button, 30 mm, 1NO/1NC, Green - 52BT6D3ABV

Name: Illuminated Push Button, 30 mm, 1NO/1NC, Green - 52BT6D3ABV
Brand: Siemens
SKU: 52BT6D3ABV
Price: 108.09 USD
Availability: InStock

Siemens

SKU:

52BT6D3ABV

UPC:

887621496791

Availability:

In Stock

(No reviews yet)

Illuminated Push Button, 30 mm, Maintained/Momentary Action, Round Extended Guarded Button Type of Operator, Head Material Plastic, Contact Form 1NO/1NC, Bezel Black Epoxy Coated Zinc Die Cast, Color Green, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/P600, Number of Operators 1, NEMA Rating 1, 12, 13, 3, 3R, 4, 4X, IP Rating IP10, IP11, IP14, IP52, IP54, IP56, IP66, Legend Not Applicable, Standards CSA, REACH, UL Listed, Terminal Connection Pressure Plate

Country of Origin:: Mexico
Item:: Illuminated Push Button
Contact Rating:: 10A @ 600V AC
Size:: 30 mm
Action:: Maintained/Momentary
NEMA Rating:: 1, 12, 13, 3, 3R, 4, 4X
Lamp Voltage:: 24V AC/DC
Lamp Type:: LED
Type of Operator:: Round Extended Guarded Button
Head Material:: Plastic
Contact Form:: 1NO/1NC
Legend:: Not Applicable
Number of Operators:: 1
Bezel:: Black Epoxy Coated Zinc Die Cast
Color:: Green
Lamp Module Voltage:: 24V AC/DC
Bezel Material:: Epoxy Coated Zinc Die Cast
Lamp Module Type:: Full Voltage
Voltage:: 24V AC/DC
Standards:: CSA, REACH, UL Listed
Basic Material:: Epoxy
NEMA Contact Rating Designation:: A600/P600
Terminal Connection:: Pressure Plate
Contact Type:: 1NO/1NC
Replacement Lamp:: Mfr. No. 52AED3
IP Rating:: IP10, IP11, IP14, IP52, IP54, IP56, IP66
DC Contact Rating:: Not Rated
AC Contact Rating:: 10 A @ 600 V
Features:: Bifurcated Movable Contacts, Boots Not Required, NEMA A600/P600 Contacts, Octagonal Mounting Nuts, Positive Indexing Selectors, Positively Driven Contacts, Touchsafe Terminals
Series:: 52
Product Type:: Push Button Operators
NEMA Enclosure Rating:: 4X
Head Color:: Green
Operator Material:: Epoxy
Maintained Action Release:: Push/Pull
Mushroom Head Diameter:: Not Applicable
Number of Indicator Lights:: 0
Lamp Voltage - Maximum:: 24 V
Mechanical Operating Durability:: 3.00 x 10^5
Operating Temperature - Maximum:: 158 Degrees F
Hazardous Location Specification:: Class I, Div 2, Group A, B, C, D
Operator Illumination:: Illuminated
Overall Height:: 4.24 in
Push Button Style:: Extended
Operating Temperature - Minimum:: 31 Degrees F
Resistance Properties:: Corrosion Resistant, Oil and Grease Resistant, Watertight
Overall Width:: 2.15 in
Legend Background Color:: Not Applicable
Panel Cutout Diameter:: 30 mm
Manufacturer Warranty Length:: 1 yr
Legend Color:: Not Applicable
Operator Voltage Rating - Maximum:: 600 V AC
Package Quantity:: 1
