Illuminated Push Button, 22mm, Red - XB4BW34G5

Illuminated Push Button, 22mm, Red - XB4BW34G5

Schneider Electric
SKU:
XB4BW34G5
|
UPC:
785901381549
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Illuminated Push Button, 22 mm, Momentary Action, Round Guarded Button Type of Operator, Head Material Metal, Contact Form 1NO/1NC, Bezel Chrome Plated Metal, Color Red, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/Q600, Number of Operators 1, NEMA Rating 1, 12, 13, 2, 3, 4, 4X, IP Rating IP66, IP67, IP69, IP69K, Legend Not Applicable
Additional Information
Country of Origin:
France
Item:
Illuminated Push Button
Voltage:
120V AC
Action:
Momentary
Color:
Red
Lamp Type:
LED
Type of Operator:
Round Guarded Button
Head Material:
Metal
Shape:
Round
Terminal Connection:
Screw Clamp
Contact Form:
1NO/1NC
Bezel:
Chrome Plated Metal
Size:
22 mm
Lamp Module Type:
Full Voltage
Lamp Module Voltage:
120V AC
Basic Material:
Metal
NEMA Contact Rating Designation:
A600/Q600
Lamp Voltage:
120V AC
Contact Rating:
10A @ 600V AC
Standards:
Bureau Veritas, CSA, CSA C22.2 No.14, DNV, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, EN/IEC 60947-5-5, Germanischer Lloyd (GL), JIS C8201-1, JIS C8201-5-1, Lloyd's Register, REACH, RoHS, UL 508, UL Listed, WEEE
Number of Operators:
1
NEMA Rating:
1, 12, 13, 2, 3, 4, 4X
IP Rating:
IP66, IP67, IP69, IP69K
Contact Type:
1NO/1NC
Length:
57 mm
Height:
47 mm
Width:
30 mm
Average Life:
100000 hr
Product Type:
Push Button Operators
Legend:
Not Applicable
Type:
Steady Signal
Bezel Material:
Chrome
NEMA Enclosure Rating:
13, 4X
Push Button Style:
Flush
Head Color:
Red
Mechanical Operating Durability:
1.00 x 10^7
AC Contact Rating:
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
Manufacturer Warranty Length:
18 mo
Features:
Quick Assembly, Quick Disassembly
Overall Width:
1.18 in
Operating Temperature - Minimum:
-40 Degrees F
Hazardous Location Specification:
Not Applicable
Overall Depth:
2.24 in
Overall Height:
1.85 in
DC Contact Rating:
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @ 125 V
Resistance Properties:
Dust Resistant, Impact Resistant, Vibration Resistant, Watertight
Legend Color:
Not Applicable
Number of Indicator Lights:
0
Operator Voltage Rating - Maximum:
600 V AC/DC
Lamp Voltage - Maximum:
120 V AC
Legend Background Color:
Not Applicable
Series:
XB4
Operator Material:
Metal
Operator Illumination:
Illuminated
Mushroom Head Diameter:
Not Applicable
Maintained Action Release:
Not Applicable
Panel Cutout Diameter:
22 mm
Operating Temperature - Maximum:
158 Degrees F
Package Quantity:
1
