Illuminated Multi-Head Operator with Contact, 22 mm, 1NO/1NC, Rectangle - XB5AW73731G5

Illuminated Multi-Head Operator with Contact, 22 mm, 1NO/1NC, Rectangle - XB5AW73731G5

Schneider Electric
SKU:
XB5AW73731G5
|
UPC:
785901365884
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Multihead Operator, 22 mm, Momentary/Momentary/Momentary Action, (1) Extended Button, (1) Flush Button, (1) Light Type of Operator, Head Material Plastic, Contact Form 1NO/1NC, Bezel Plastic, Color Green/Red, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/Q600, Number of Operators 3, NEMA Rating 1, 12, 3, 4, 4X, IP Rating IP66, IP69, IP69K, Legend I/O, Legend/Background Color White/Green, White/Red
Additional Information
Country of Origin:
France
Item:
Multihead Operator
Basic Material:
Plastic
Number of Heads:
3
Contact Form:
1NO/1NC
Legend:
I/O
Legend/Background Color:
White/Green, White/Red
Lamp Voltage:
120V AC
Type of Operator:
(1) Extended Button, (1) Flush Button, (1) Light
Lamp Type:
LED
Number of Operators:
3
NEMA Rating:
1, 12, 3, 4, 4X
Series:
XB5
Size:
22 mm
Contact Rating:
10A @ 600V AC
Standards:
Bureau Veritas, CSA, CSA C22.2 No.14, DNV, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, Germanischer Lloyd (GL), JIS C8201-1, JIS C8201-5-1, Lloyd's Register, REACH, RoHS, UL 508, UL Listed, WEEE
Shape:
Rectangle
Action:
Momentary/Momentary/Momentary
Head Material:
Plastic
Bezel Material:
Plastic
Replacement Lamp:
Mfr. No 25501-01-027
Lamp Module Type:
Full Voltage
IP Rating:
IP66, IP69, IP69K
NEMA Contact Rating Designation:
A600/Q600
Includes:
120V Light, White I on Green Background and White O on Red Background
Lamp Module Voltage:
120V AC
Terminal Connection:
Screw Clamp
AC Contact Rating:
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
Width:
30 mm
DC Contact Rating:
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @ 125 V
Depth:
59 mm
Height:
50 mm
Legend Color:
White
Product Type:
Multihead Operators
Resistance To Electromagnetic Fields:
10 V/m IEC 61000-4-3
Head Type:
standard
[Ith] Conventional Free Air Thermal Current:
10 A EN/IEC 60947-5-1
Connections - Terminals:
screw clamp terminals, <= 2 x 1.5 mm² with cable end EN/IEC 60947-1 || screw clamp terminals, >= 1 x 0.22 mm² without cable end EN/IEC 60947-1 || spring terminals, <= 2 x 1.5 mm² with cable end EN/IEC 60947-1 || spring terminals, >= 1 x 0.22 mm² with
Operating Travel:
1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)
Positive Opening:
with EN/IEC 60947-5-1 appendix K
Operating Force:
3.5 N NC changing electrical state || 3.8 N NO changing electrical state
Ip Degree Of Protection:
IP66 IEC 60529 || IP69 IEC 60529 || IP69K
Operators Description:
green ''I'' - red ''O''
Light Source Colour:
white
Resistance To Fast Transients:
2 kV IEC 61000-4-4
Short-Circuit Protection:
10 A cartridge fuse gG EN/IEC 60947-5-1
Resistance To Electrostatic Discharge:
6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2
Electrical Reliability:
Λ < 10exp(-6) 5 V 1 mA in clean environment EN/IEC 60947-5-4 || Λ < 10exp(-8) 17 V 5 mA in clean environment EN/IEC 60947-5-4
Bulb Base:
integral LED
Ambient Air Temperature For Storage:
-40-70°C
Product Certifications:
UL Listed || GL || LROS (Lloyds register of shipping) || DNV || BV || CSA
Contacts Material:
silver alloy (Ag/Ni)
Ik Degree Of Protection:
IK05 IEC 50102
Resistance To High Pressure Washer:
7000000 Pa 55°C 0.1 m
Surge Withstand:
1 kV IEC 61000-4-5
Overvoltage Category:
class II IEC 61140
Electrical Durability:
1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C || 1000000 cycles
Colour Of Marking:
white marking when green, red or black caps || black marking when white caps
Operator Profile:
1 flush - 1 projecting push-buttons - 1 central pilot light, green flush, I white) || red projecting, O white)
Contacts Type And Composition:
1 NO + 1 NC
Product Or Component Type:
illuminated double-headed push-button
[Ui] Rated Insulation Voltage:
600 V 3)EN 60947-1
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Vibration Resistance:
5 gn 2-500 Hz)IEC 60068-2-6
Light Source:
protected LED
[Ie] Rated Operational Current:
3 A 240 V, AC-15, A600 EN/IEC 60947-5-1 || 6 A 120 V, AC-15, A600 EN/IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 EN/IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 EN/IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 EN/IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 EN
Supply Voltage Limits:
94-132 V AC
Protective Treatment:
TH
Device Presentation:
complete product
Nema Degree Of Protection:
NEMA 13 || NEMA 4X
Device Short Name:
XB5
Shape Of Screw Head:
cross JIS No 1 || cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
Electromagnetic Emission:
class B IEC 55011
Mounting Diameter:
22 mm
Mechanical Durability:
1000000 cycles
Tightening Torque:
0.8-1.2 N.m EN 60947-1
Fixing Collar Material:
plastic
Terminals Description Iso N°1:
(11-12)NC || (13-14)NO
[Uimp] Rated Impulse Withstand Voltage:
6 kV EN 60947-1
Current Consumption:
14 mA
Signalling Type:
steady
Ambient Air Temperature For Operation:
-40-70°C
Contacts Usage:
standard contacts
Shape Of Signaling Unit Head:
rectangular
Contact Operation:
slow-break
[Us] Rated Supply Voltage:
110 to 120 V AC 50/60 Hz
Operator Illumination:
Illuminated
Hazardous Location Specification:
Not Applicable
Mechanical Operating Durability:
1.00 x 10^6
Resistance Properties:
Chemical Resistant, Dust Resistant, Impact Resistant, Vibration Resistant, Watertight
Manufacturer Warranty Length:
18 mo
Operating Temperature - Minimum:
-40 Degrees F
Overall Width:
1.18 in
Overall Depth:
2.32 in
Mushroom Head Diameter:
Not Applicable
Push Button Style:
Flush
Overall Height:
1.97 in
Operating Temperature - Maximum:
158 Degrees F
Panel Cutout Diameter:
22 mm
Lamp Voltage - Maximum:
120 V AC
Legend Background Color:
Green/Red
Operator Material:
Plastic
Operator Voltage Rating - Maximum:
600 V AC/DC
Head Color:
Green, Red
Number of Indicator Lights:
0
NEMA Enclosure Rating:
13, 4X
Maintained Action Release:
Not Applicable
Package Quantity:
1
