Illuminated Emergency Stop Push Button - M22-PVLT-K01-R

Illuminated Emergency Stop Push Button - M22-PVLT-K01-R

Eaton
SKU:
M22-PVLT-K01-R
|
UPC:
786685900438
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Emergency Stop Push Button, 22 mm, Maintained Action, 45mm Mushroom Head Type of Operator, Head Material Plastic, Contact Form 1NC, Bezel Polycarbonate, Color Red, Contact Rating 3A @ 24 DC, 6A @ 230V AC, NEMA Contact Rating Designation AC-15, DC-13, Number of Operators 1, NEMA Rating 1, 13, 2, 3, 4, 4X, IP Rating IP67, IP69K, Standards Bureau Veritas, CCC, CE, CSA, GOST-R, Lloyd's Register, UL Listed, Terminal Connection Screw Clamp
Additional Information
Country of Origin:
Germany
Item:
Emergency Stop Push Button
Color:
Red
Basic Material:
Plastic
Number of Operators:
1
Head Material:
Plastic
NEMA Rating:
1, 13, 2, 3, 4, 4X
Lamp Module Voltage:
30V AC/DC
Action:
Maintained
Contact Form:
1NC
Lamp Module Type:
Transformer
Contact Rating:
3A @ 24 DC, 6A @ 230V AC
IP Rating:
IP67, IP69K
Size:
22 mm
Standards:
Bureau Veritas, CCC, CE, CSA, GOST-R, Lloyd's Register, UL Listed
Terminal Connection:
Screw Clamp
Lamp Type:
LED
Bezel:
Polycarbonate
NEMA Contact Rating Designation:
AC-15, DC-13
Type of Operator:
45mm Mushroom Head
Features:
Field Conversion from Momentary to Maintained can be Done, Includes Contact Block Mounting Adapter
Product Type:
Emergency Stop Push Buttons
Type:
Emergency Stop
Bezel Material:
Nylon
Environmental rating:
IP67, IP69K, NEMA 4X, NEMA 13
Certifications:
CSA Certified
Product Width:
5 in
Actuator:
Knob, twist-to-release
Illumination:
Illuminated
Compliances:
CE Marked
Product Length/Depth:
7 in
Product Height:
1.5 in
Button color:
Red
Voltage rating:
12-30 Vac/dc
Series:
M22
Actuator function:
Maintained
Contact configuration:
1 NC
Product Name:
Eaton M22 modular pushbutton
Push Button Style:
Mushroom Head
Operator Voltage Rating - Maximum:
30 V AC/DC
Mushroom Head Diameter:
40 mm
Operating Temperature - Minimum:
-13 Degrees F
Overall Depth:
2.77 in
DC Contact Rating:
3 A @ 24 V
Operating Temperature - Maximum:
158 Degrees F
Manufacturer Warranty Length:
1 yr
NEMA Enclosure Rating:
1, 12, 13, 2, 3, 3R, 4, 4X
Overall Height:
1 in
Maintained Action Release:
Twist
Operator Illumination:
Illuminated
Number of Indicator Lights:
0
Panel Cutout Diameter:
22 mm
Mechanical Operating Durability:
1.00 x 10^6
AC Contact Rating:
6 A @ 230 V
Head Color:
Red
Resistance Properties:
Corrosion Resistant
Lamp Voltage - Maximum:
30 V AC/DC
Operator Material:
Plastic
Overall Width:
1 in
Package Quantity:
1
