IEC Pin & Sleeve Plug, 30 A, 480V AC, IEC Grounding, 15 hp, 3 Poles, 3 Phase, 4 Wires, Red - HBL430P7W

IEC Pin & Sleeve Plug, 30 A, 480V AC, IEC Grounding, 15 hp, 3 Poles, 3 Phase, 4 Wires, Red - HBL430P7W

Hubbell
SKU:
HBL430P7W
|
UPC:
783585404585
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Pin and Sleeve Plug, Current Rating 30 A, Horsepower Rating 15 hp, Housing Color Red, IP Rating IP67, Number of Poles 3, Number of Wires 4, Phase Three, Voltage Rating 480V AC, Wire Connection Type Screw Terminals, Cap Type No Cap or Cover, Connection Orientation Straight, For Maximum Cable Diameter 1.25 in, For Minimum Cable Diameter 0.5 in, Grounding Grounded, Grounding Style IEC, Housing Material Polybutylene Terephthalate, Maximum Wire Size 8 AWG, Minimum Wire Size 12 AWG
Additional Information
Country of Origin:
United States
Item - Plugs and Receptacles:
Watertight Pin and Sleeve Plug
Body Material - Pin and Sleeve:
Zytel 801 Nylon
Amps - Plugs and Receptacles:
30
Voltage - Plugs and Receptacles:
480V AC
Color - Plugs and Receptacles:
Red
Number of Poles:
3
Number of Wires:
4
Phase - Electrical:
3
Switch Rated:
No
Grounding Style:
IEC
Body Material:
Zytel 801 Nylon
Item:
IEC Pin and Sleeve Plug
Standards:
CSA Certified C22.2 No. 182.1, UL E146032, UL IEC 60309-1
Amps:
30
Voltage:
480VAC
HP:
7 1/2 hp
Phase:
Three
Color:
Red
Features:
Gasketed Sealing Ring Provides Watertight Seal
Overall Length:
8.037 in
Minimum Operating Temperature:
-40 Degrees C
Connection Orientation:
Straight
Reverse Service:
No
Horsepower Rating:
15 hp
Current Rating:
30 A
Power Indicating Light:
No
IP Rating:
IP67
Cap Type:
No Cap or Cover
Minimum Wire Size:
12 AWG
Housing Color:
Red
Resistance Properties:
Impact Resistant, Moisture Resistant, Watertight
Wire Connection Type:
Screw Terminals
Grounding:
Grounded
UL 94 Flammability Rating:
HB
Shrouded:
Yes
For Maximum Cable Diameter:
1.25 in
For Minimum Cable Diameter:
0.5 in
Maximum Operating Temperature:
75 Degrees C
NEMA Enclosure Rating:
4X
Maximum Wire Size:
8 AWG
Voltage Rating:
480V AC
Housing Material:
Non-Metallic
Max. Voltage:
600V
Hub Style:
Standard
Package Quantity:
1
