IEC Pin and Sleeve Plug, 2P, 3W, 20A, 480V - HBL320P7W

IEC Pin and Sleeve Plug, 2P, 3W, 20A, 480V - HBL320P7W

Hubbell
SKU:
HBL320P7W
|
UPC:
783585403410
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Pin and Sleeve Plug, Current Rating 20 A, Horsepower Rating 5 hp, Housing Color Red, IP Rating IP67, Number of Poles 2, Number of Wires 3, Phase Single, Voltage Rating 480V AC, Wire Connection Type Screw Terminals, Cap Type No Cap or Cover, Connection Orientation Straight, For Maximum Cable Diameter 0.78 in, For Minimum Cable Diameter 0.36 in, Grounding Grounded, Grounding Style IEC, Housing Material Polybutylene Terephthalate, Maximum Wire Size 10 AWG, Minimum Wire Size 14 AWG
Additional Information
Country of Origin:
United States
Item - Plugs and Receptacles:
Watertight Pin and Sleeve Plug
Body Material - Pin and Sleeve:
Zytel 801 Nylon
Amps - Plugs and Receptacles:
20
Voltage - Plugs and Receptacles:
480V AC
Color - Plugs and Receptacles:
Red
Number of Poles:
2
Number of Wires:
3
Phase - Electrical:
1
Switch Rated:
No
Grounding Style:
IEC
Features:
Gasketed Sealing Ring Provides Watertight Seal, Raised Collar Surrounds Each Phase Pin, Solid One-Piece Pins Machined from Solid Brass
Color:
Red
Amps:
20
Standards:
CSA Certified LR280C, IEC 60309-1, IEC 60309-2, UL 1682, UL 1686C2
Item:
IEC Pin and Sleeve Plug
Body Material:
Zytel 801 Nylon
Voltage:
480VAC
Phase:
Single
Material:
Composite
Overall Length:
6.61 in
Application:
High Ampacity Connections
Power Indicating Light:
No
Current Rating:
20 A
For Maximum Cable Diameter:
0.78 in
Wire Connection Type:
Screw Terminals
Housing Material:
Non-Metallic
Minimum Wire Size:
14 AWG
Voltage Rating:
480V AC
Connection Orientation:
Straight
For Minimum Cable Diameter:
0.36 in
Housing Color:
Red
Reverse Service:
No
Horsepower Rating:
5 hp
Minimum Operating Temperature:
-40 Degrees C
Maximum Wire Size:
10 AWG
IP Rating:
IP67
Shrouded:
Yes
Cap Type:
No Cap or Cover
Resistance Properties:
Impact Resistant, Moisture Resistant, Watertight
Grounding:
Grounded
UL 94 Flammability Rating:
HB
NEMA Enclosure Rating:
4X
Maximum Operating Temperature:
75 Degrees C
Hub Style:
Standard
Max. Voltage:
600V
Type:
Watertight Plug
Current / Amperage Rating:
20 A
Cord Type:
All Portable
Amperage Rating:
20 A
Voltage Rating Description:
480 VAC
Display Size:
Standard Sized
Industry Standard(s):
CSA Certified File LR280C UL Classified to IEC 60309-1 IEC 60309-2 UL Standard UL1682 and UL 1686C2
Nema Rating:
Non-NEMA
OEM Brand Name:
Hubbell Wiring Device-Kellems
Series:
HBL Heavy Duty
Performance:
Electrical - Current Interrupting - Certified for current interrupting at full rated current Electrical - Dielectric Voltage - 3000V AC Electrical - Max. Working Voltage - 600V RMS Environmental - Flammability - HB or better per UL 94 or CSA C22.2 No
Connectivity:
Pressure Terminal Screws
Style:
Standard Service
Environmental Conditions:
Watertight
Wire Size:
#14 AWG to #10 AWG
Item Type:
Male Plug
Material - Mounting Hardware:
Cord Mounted
Package Quantity:
1
