IEC Magnetic Contactor, 3 Poles, 480 V AC, 12 A, Reversing: No - XTCE012B10C

IEC Magnetic Contactor, 3 Poles, 480 V AC, 12 A, Reversing: No - XTCE012B10C

Eaton
SKU:
XTCE012B10C
|
UPC:
786685353777
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Magnetic Contactor, Auxiliary Contact Form 1NO, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 415/480V AC, Number of Poles 3, Full Load Current - Inductive 12 A, Full Load Current - Resistive 22 A, Reversing Capability Non-Reversing, Overall Height 2 in, Overall Width 3 in, Terminal Connection Type Screw Terminals, Frame Size B, Mounting Style DIN Rail, Panel, Series XT, Number of Auxillary Contacts 1, Contactor Style IEC, Horsepower @ Three Phase - 240V AC 3 hp
Additional Information
Country of Origin:
Romania
Item:
IEC Magnetic Contactor
Full Load Amps-Inductive:
12 A
Full Load Amps-Resistive:
22 A
Number of Poles:
3
Coil Volts:
480 V AC
Reversing:
No
HP @ 1 Phase - 120V:
1 hp
HP @ 1 Phase - 240V:
2 hp
Height:
1.77 in
Width:
1.77 in
HP @ 3 Phase - 208V:
3 hp
HP @ 3 Phase - 240V:
3 hp
HP @ 3 Phase - 575V:
10 hp
Depth:
2.95 in
Enclosure NEMA Rating:
No Enclosure
HP @ 3 Phase - 480V:
10 hp
Aux. Contact Configuration:
1NO
Hz:
50/60
Action:
Non-Reversing
HP @ 1 Phase - 230V:
2
Auxiliary Contact Form:
1NO
Frame / Series / Class / Code:
Frame B
Standards:
CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
NEMA Size:
Not Applicable
Series:
XT
Type:
Full voltage non-reversing contactor
Electrical Connection:
Screw Terminals
IP Rating:
IP20
Product Length/Depth:
3 in
Compliances:
CE Marked
Product Name:
Eaton XT IEC contactor
Contact Configuration:
1 NO
Product Height:
2 in
Frequency Rating:
50-60 Hz
Certifications:
UL Listed;CSA Certified;IEC 60947;EN 60947
Product Width:
3 in
Hp Rating - Max:
1, 2, 2/ 3, 3, 10, 10 hp (1/3PH @115,200,230/200,230,460,575 V)
Amperage Rating:
12A
Coil Voltage:
415/480V AC
Overall Height:
2 in
Mounting Style:
DIN Rail, Panel
Horsepower @ Three Phase - 208V AC:
3 hp
Horsepower @ Single Phase - 120V AC:
1 hp
Horsepower @ Three Phase - 480V AC:
10 hp
Full Load Current - Resistive:
22 A
Frame Size:
B
Terminal Connection Type:
Screw Terminals
Contactor Style:
IEC
Reversing Capability:
Non-Reversing
Maximum Operating Temperature:
122 Degrees F
NEMA Enclosure Rating:
No Enclosure
Horsepower @ Three Phase - 240V AC:
3 hp
Full Load Current - Inductive:
12 A
Embedded Surge Suppressor:
Yes
Maximum Voltage Rating:
690V AC
Minimum Operating Temperature:
-13 Degrees F
Frequency:
50/60 Hz
Overall Depth:
3 in
NEMA Enclosure Material:
Not Applicable
Horsepower @ Three Phase - 600V AC:
10 hp
Overall Width:
3 in
Mechanical Operating Durability:
10,000,000
Horsepower @ Single Phase - 240V AC:
2 hp
Response Time:
Less Than12 msec (DC Operated Opening Delay), Less Than18 msec (AC Operated Opening Delay), Less Than21 msec (AC Operated Closing Delay), Less Than31 msec (DC Operated Opening Delay)
Includes Auxiliary Contacts:
Yes
Electrical Operating Durability:
1,000,000
Number of Auxillary Contacts:
1
Package Quantity:
1
