IEC Magnetic Contactor, 3 Poles, 24 V DC, 7 A, Reversing: No - XTCE007B01TD

IEC Magnetic Contactor, 3 Poles, 24 V DC, 7 A, Reversing: No - XTCE007B01TD

Eaton
SKU:
XTCE007B01TD
|
UPC:
786685363356
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Magnetic Contactor, Auxiliary Contact Form 1NC, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 24V DC, Number of Poles 3, Full Load Current - Inductive 7 A, Full Load Current - Resistive 22 A, Reversing Capability Non-Reversing, Overall Height 3 in, Overall Width 1.77 in, Terminal Connection Type Screw Terminals, Frame Size B, Mounting Style DIN Rail, Panel, Series XT, Number of Auxillary Contacts 1, Contactor Style IEC, Horsepower @ Three Phase - 240V AC 2 hp
Additional Information
Country of Origin:
Romania
Item:
IEC Magnetic Contactor
Full Load Amps-Inductive:
7 A
Full Load Amps-Resistive:
22 A
Action:
Non-Reversing
Type:
Full voltage non-reversing contactor
Number of Poles:
3
Coil Volts:
24 V DC
Reversing:
No
HP @ 1 Phase - 120V:
1/4 hp
HP @ 1 Phase - 230V:
1
HP @ 1 Phase - 240V:
1 hp
Height:
1.77 in
Width:
1.77 in
HP @ 3 Phase - 208V:
1 1/2 hp
Depth:
2.95 in
HP @ 3 Phase - 240V:
2 hp
HP @ 3 Phase - 575V:
5 hp
HP @ 3 Phase - 480V:
3 hp
Enclosure NEMA Rating:
No Enclosure
Aux. Contact Configuration:
1NC
Standards:
CSA, UL Listed
Auxiliary Contact Form:
1NC
Frame / Series / Class / Code:
Frame B
NEMA Size:
Not Applicable
Series:
XT
IP Rating:
IP20
Electrical Connection:
Screw Terminals
Contact Configuration:
1 NC
Coil Voltage:
24V DC
Certifications:
UL Listed;CSA Certified
Product Height:
3 in
Product Name:
Eaton XT IEC contactor
Amperage Rating:
7A
Hp Rating - Max:
0.25, 0.75, 1/ 1.5, 2, 3, 5 hp (1/3PH @115,200,230/200,230,460,575 V)
Electrical Operating Durability:
1000 (AC-3 400V Ie), 300 (AC-4 400V Ie), 800 (AC-1 400V Ie)
Overall Width:
1.77 in
Horsepower @ Single Phase - 240V AC:
1 hp
Includes Auxiliary Contacts:
Yes
NEMA Enclosure Rating:
No Enclosure
Maximum Voltage Rating:
690V AC
Full Load Current - Inductive:
7 A
Terminal Connection Type:
Screw Terminals
Horsepower @ Single Phase - 120V AC:
1/4 hp
Mechanical Operating Durability:
10,000,000
Embedded Surge Suppressor:
Yes
Number of Auxillary Contacts:
1
Mounting Hole Distance - Height:
2.36 in
Mounting Hole Diameter:
0.16 in
Maximum Operating Temperature:
122 Degrees F
Horsepower @ Three Phase - 600V AC:
5 hp
Contactor Style:
IEC
Horsepower @ Three Phase - 208V AC:
1 1/2 hp
Frame Size:
B
Overall Depth:
2.95 in
Reversing Capability:
Non-Reversing
Response Time:
Less Than12 msec (DC Operated Opening Delay), Less Than18 msec (AC Operated Opening Delay), Less Than21 msec (AC Operated Closing Delay), Less Than31 msec (DC Operated Opening Delay)
Minimum Operating Temperature:
-13 Degrees F
Frequency:
50/60 Hz
Horsepower @ Three Phase - 240V AC:
2 hp
Mounting Hole Distance - Width:
1.38 in
Mounting Style:
DIN Rail, Panel
Horsepower @ Three Phase - 480V AC:
3 hp
Full Load Current - Resistive:
22 A
Overall Height:
3 in
NEMA Enclosure Material:
Not Applicable
Package Quantity:
1
