IEC Magnetic Contactor, 3 Poles, 24 V DC, 65 A, Reversing: No - LC1D65ABD

IEC Magnetic Contactor, 3 Poles, 24 V DC, 65 A, Reversing: No - LC1D65ABD

Schneider Electric
SKU:
LC1D65ABD
|
UPC:
785901565468
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Magnetic Contactor, Auxiliary Contact Form 1NO/1NC, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 24V DC, Number of Poles 3, Full Load Current - Inductive 65 A, Full Load Current - Resistive 80 A, Reversing Capability Non-Reversing, Overall Height 4.8 in, Overall Width 2.17 in, Terminal Connection Type Screw Clamp Terminals, Mounting Style DIN Rail, Plate, Series TeSys Deca, Number of Auxillary Contacts 2, Contactor Style IEC
Additional Information
Country of Origin:
France
Item:
IEC Magnetic Contactor
Full Load Amps-Inductive:
65 A
Full Load Amps-Resistive:
80 A
Action:
Non-Reversing
Number of Poles:
3
Coil Volts:
24 V DC
Reversing:
No
HP @ 1 Phase - 120V:
5 hp
HP @ 1 Phase - 230V:
10
HP @ 1 Phase - 240V:
10 hp
Height:
4.8 in
Width:
2.17 in
HP @ 3 Phase - 208V:
20 hp
HP @ 3 Phase - 575V:
50 hp
HP @ 3 Phase - 240V:
20 hp
Depth:
4.72 in
HP @ 3 Phase - 480V:
40 hp
Enclosure NEMA Rating:
No Enclosure
Aux. Contact Configuration:
1NO/1NC
Hz:
50/60
Standards:
CCC, CSA, CSA C22.2 No 14, EN 60947-4-1, EN 60947-5-1, GOST, IEC 60335-1, IEC 60947-4-1, IEC 60947-5-1, UL 508, UL Listed
Auxiliary Contact Form:
1NO/1NC
Includes:
Everlink Power Connections
NEMA Size:
Not Applicable
Series:
TeSys Deca
Features:
Built-In Bi-Directional Peak Limiting Diode Suppressor
Control Circuit Voltage Limits:
Drop-Out DC
Thermal Amperage:
10 A (at 60°C Signalling Circuit), 80 A (at 60°C Power Circuit)
Application:
Motor Control, Resistive Load
Operating Time:
42.5 to 57.5 ms (Closing), 16 to 24 ms (Opening)
Impulse Withstand Voltage:
6 kV
Rated Making Capacity:
140 A (AC Signalling Circuit), 250 A (DC Signalling Circuit), 1000 A @ 440V (Power Circuit)
Electrical Connection:
Screw Clamp Terminals
Net Weight:
0.935 kg
Includes Protective Cover:
Yes
Non-Overlap Time:
1.5 ms
Environmental Attributes:
Mercury Free, PVC Free, Pollution Degree 3
Overvoltage Category:
CAT III
Signalling Circuit Frequency:
25 to 400 Hz
Electrical Durability:
0.5 Mcycles (80 A, AC-1, Less than 440 V); 1.45 Mcycles (65 A, AC-3, Less than 440 V); 1.45 Mcycles (65 A, AC-3e, Less than 440 V)
Fuse Amps:
10 A (Signalling Circuit), 125 A (Type 1 Power Circuit), 125 A (Type 2 Power Circuit)
Operating Speed:
3600 cycles per hr
Insulation Resistance Range:
Greater Than 10 MOhms (Signalling Circuit)
Rated Short-Time Withstand Current:
520 A (at 40°C for 10 s Power Circuit), 900 A (at 40°C for 1 s Power Circuit), 110 A (at 40°C for 10 min Power Circuit), 260 A (at 40°C for 1 min Power Circuit), 100 A (For 1 s Signalling Circuit), 120 A (For 500 ms Signalling Circuit), 140 A (Fo
Rated Breaking Capacity:
1000 A @ 440V
Rated Insulation Volts:
600/690V
IP Rating:
IP20
Tightening Torque:
1.7 Nm (Control Circuit), 2.5 to 8 Nm (Power Circuit)
Vibration Resistance:
4 G (Contactor Closed), 2 G (Contactor Open)
Switching Current:
5 mA (Signalling Circuit)
Working Height:
Up to 9842.52 ft
Rated Voltage:
690V AC, 300V DC
Switching Voltage:
17 V (Signalling Circuit)
Fire Rating:
UL 94 V1
Shock Resistance:
10 G for 11 ms (Contactor Open), 15 G for 11 ms (Contactor Closed)
Mounts On:
Plate, Rail
Mechanical Durability:
10 Mcycles
Impedance:
1.5 mOhm
Max. Operating Watts:
11 kW (at 400V AC 50/60 Hz AC-4), 18.5 kW (at 220 to 230V AC 50/60 Hz AC-3), 30 kW (at 380 to 400V AC 50/60 Hz AC-3), 37 kW (at 500V AC 50/60 Hz AC-3), 37 kW (at 660 to 690V AC 50/60 Hz AC-3), 18.5 kW (at 220 to 230V AC 50/60 Hz AC-3e), 30 kW (at 380
Max. Temperature:
850°C
Number of Normally Open Main Contacts:
3
Horsepower @ Single Phase - 120V AC:
5 hp
Reversing Capability:
Non-Reversing
Resistance Properties:
Fire Resistant, Insulation Resistant
Full Load Current - Inductive:
65 A
Includes Auxiliary Contacts:
Yes
Mounting Style:
DIN Rail, Plate
Overall Depth:
4.72 in
Horsepower @ Three Phase - 600V AC:
50 hp
Horsepower @ Three Phase - 480V AC:
40 hp
NEMA Enclosure Rating:
No Enclosure
Horsepower @ Three Phase - 240V AC:
20 hp
Overall Width:
2.17 in
Horsepower @ Three Phase - 208V AC:
20 hp
Coil Voltage:
24V DC
Electrical Operating Durability:
1,450,000, 500,000
Maximum Operating Temperature:
140 Degrees F
Frequency:
50/60 Hz
Terminal Connection Type:
Screw Clamp Terminals
Contactor Style:
IEC
Maximum Voltage Rating:
690V AC
Overall Height:
4.8 in
Number of Auxillary Contacts:
2
Mechanical Operating Durability:
10,000,000
Minimum Operating Temperature:
-40 Degrees F
Full Load Current - Resistive:
80 A
Phase:
Three
NEMA Enclosure Material:
Not Applicable
Horsepower @ Single Phase - 240V AC:
10 hp
Embedded Surge Suppressor:
Yes
Rated Short Time Withstand Current:
640 A 104°F (40°C) - 10 s for power circuit; 900 A 104°F (40°C) - 1 s for power circuit; 110 A 104°F (40°C) - 10 min for power circuit; 260 A 104°F (40°C) - 1 min for power circuit; 100 A - 1 s for signalling circuit; 120 A - 500 ms for signa
Flame Retardance:
V1 conforming to UL 94
Climatic Withstand:
IACS E10 exposure to damp heat; IEC 60947-1 Annex Q category D exposure to damp heat
Motor Power KW:
11 kW at 400 V AC 50/60 Hz (AC-4); 18.5 kW at 220 to 230 V AC 50/60 Hz (AC-3); 30 kW at 380 to 400 V AC 50/60 Hz (AC-3); 37 kW at 500 V AC 50/60 Hz (AC-3); 37 kW at 660 to 690 V AC 50/60 Hz (AC-3); 18.5 kW at 220 to 230 V AC 50/60 Hz (AC-3e); 30 kW a
Rated Insulation Voltage:
Power circuit 600 V CSA; Power circuit 600 V UL; Signalling circuit 690 V IEC 60947-1; Signalling circuit 600 V CSA; Signalling circuit 600 V UL; Power circuit 690 V IEC 60947-4-1
Maximum Horse Power Rating:
40 hp at 460/480 V AC 50/60 Hz for 3 phase motors; 5 hp at 115 V AC 50/60 Hz for 1 phase motors; 10 hp at 230/240 V AC 50/60 Hz for 1 phase motors; 20 hp at 200/208 V AC 50/60 Hz for 3 phase motors; 20 hp at 230/240 V AC 50/60 Hz for 3 phase motors;
IRMS Rated Making Capacity:
140 A AC for signalling circuit conforming to IEC 60947-5-1; 250 A DC for signalling circuit conforming to IEC 60947-5-1; 1000 A at 440 V for power circuit conforming to IEC 60947
Maximum Operating Rate:
3600 cyc/h 140°F (60°C)
Protective Treatment:
THIEC 60068-2-30
Minimum Switching Current:
5 mA for signalling circuit
Hold-In Power Consumption in W:
7.4 W 68°F (20°C)
Pollution Degree:
3
Time Constant:
34 ms
Coil Technology:
Built-in bidirectional peak limiting diode suppressor
Conventional Free Air Thermal Current:
10 A (at 140°F (60°C)) for signalling circuit; 80 A (at 140°F (60°C)) for power circuit
Product Or Component Type:
Contactor
Operating Altitude:
0 to 9842.52 ft (0 to 3000 m)
Mounting Support:
Plate; Rail
Power Dissipation Per Pole:
9.6 W AC-1; 6.3 W AC-3; 6.3 W AC-3e
Auxiliary Contacts Type:
Mechanically linked 1 NO + 1 NC IEC 60947-5-1; Mirror contact 1 NC IEC 60947-4-1
IP Degree Of Protection:
IP20 front face IEC 60529
Contactor Application:
Motor control; Resistive load
Protective Cover:
With
Rated Operational Current:
80 A (at Less than 140°F (60°C)) at Less than or Equal to 440 V AC AC-1 for power circuit; 65 A (at Less than 140°F (60°C)) at Less than or Equal to 440 V AC AC-3 for power circuit; 65 A (at Less than 140°F (60°C)) at Less than or Equal to 440
Auxiliary Contact Composition:
1 NO + 1 NC
Contact Compatibility:
M4
Insulation Resistance:
Greater than 10 MOhm for signalling circuit
Product Certifications:
GOST; UL; CCC; CSA
Poles Description:
3P
Mechanical Robustness:
Vibrations contactor open 2 Gn, 5 to 300 Hz); Vibrations contactor closed 4 Gn, 5 to 300 Hz); Shocks contactor closed 15 Gn for 11 ms); Shocks contactor open 10 Gn for 11 ms)
Utilisation Category:
AC-4; AC-1; AC-3; AC-3e
Fire Resistance:
1562°F (850°C) IEC 60695-2-1
Rated Impulse Withstand Voltage:
6 kV IEC 60947
Pole Contact Composition:
3 NO
Minimum Switching Voltage:
17 V for signalling circuit
Permissible Ambient Air Temperature Around The Device:
-40 to 140°F (-40 to 60°C); 140 to 158°F (60 to 70°C) with derating
Connections - Terminals:
Control circuit
Control Circuit Type:
DC standard
Safety Reliability Level:
B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1; B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1
Average Impedance:
1.5 mOhm - Ith 80 A 50 Hz for power circuit
Compatibility Code:
LC1D
Rated Operational Voltage:
Power circuit Less than or Equal to 690 V AC 25 to 400 Hz; Power circuit Less than or Equal to 300 V DC
Inrush Power in W:
19 W 68°F (20°C))
Associated Fuse Rating:
10 A gG for signalling circuit conforming to IEC 60947-5-1; 125 A gG at Less than or Equal to 690 V coordination type 1 for power circuit; 125 A gG at Less than or Equal to 690 V coordination type 2 for power circuit
Package Quantity:
1
