IEC Magnetic Contactor, 3 Poles, 24 V DC, 32 A, Reversing: No - XTCE032C10TD

IEC Magnetic Contactor, 3 Poles, 24 V DC, 32 A, Reversing: No - XTCE032C10TD

Eaton
SKU:
XTCE032C10TD
|
UPC:
786685363158
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Magnetic Contactor, Auxiliary Contact Form 1NO, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 24V DC, Number of Poles 3, Full Load Current - Inductive 32 A, Full Load Current - Resistive 45 A, Reversing Capability Non-Reversing, Overall Height 2 in, Overall Width 3.5 in, Terminal Connection Type Screw Terminals, Frame Size C, Mounting Style DIN Rail, Panel, Series XT, Number of Auxillary Contacts 1, Contactor Style IEC, Horsepower @ Three Phase - 240V AC 10 hp
Additional Information
Country of Origin:
Romania
Item:
IEC Magnetic Contactor
Full Load Amps-Inductive:
32 A
Action:
Non-Reversing
Full Load Amps-Resistive:
45 A
Type:
Full voltage non-reversing contactor
Number of Poles:
3
Coil Volts:
24 V DC
Reversing:
No
HP @ 1 Phase - 230V:
5
HP @ 1 Phase - 120V:
3 hp
Height:
1.77 in
HP @ 1 Phase - 240V:
5 hp
HP @ 3 Phase - 208V:
10 hp
Width:
1.77 in
HP @ 3 Phase - 240V:
10 hp
Depth:
3.82 in
HP @ 3 Phase - 575V:
25 hp
HP @ 3 Phase - 480V:
20 hp
Enclosure NEMA Rating:
No Enclosure
Aux. Contact Configuration:
1NO
Frame / Series / Class / Code:
Frame C
Standards:
CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
Auxiliary Contact Form:
1NO
NEMA Size:
Not Applicable
Series:
XT
IP Rating:
IP20
Electrical Connection:
Screw Terminals
Product Width:
3.5 in
Compliances:
CE Marked
Coil Voltage:
24V DC
Product Length/Depth:
4 in
Hp Rating - Max:
3, 5, 5/ 10, 10, 20, 25 hp (1/3PH @115,200,230/200,230,460,575 V)
Contact Configuration:
1 NO
Product Name:
Eaton XT IEC contactor
Product Height:
2 in
Amperage Rating:
32A
Frame Size:
C
Certifications:
UL Listed;CSA Certified;IEC 60947;EN 60947
Mounting Hole Distance - Height:
2.95 in
Mounting Style:
DIN Rail, Panel
Full Load Current - Resistive:
45 A
NEMA Enclosure Rating:
No Enclosure
Horsepower @ Three Phase - 480V AC:
20 hp
Frequency:
50/60 Hz
Horsepower @ Three Phase - 208V AC:
10 hp
Electrical Operating Durability:
300 (AC-4 400V Ie), 800 (AC-1 400V Ie), 800 (AC-3 400V Ie)
Minimum Operating Temperature:
-13 Degrees F
Terminal Connection Type:
Screw Terminals
Contactor Style:
IEC
NEMA Enclosure Material:
Not Applicable
Maximum Operating Temperature:
122 Degrees F
Overall Depth:
4 in
Overall Width:
3.5 in
Reversing Capability:
Non-Reversing
Horsepower @ Three Phase - 600V AC:
25 hp
Horsepower @ Three Phase - 240V AC:
10 hp
Embedded Surge Suppressor:
Yes
Mounting Hole Diameter:
0.16 in
Horsepower @ Single Phase - 240V AC:
5 hp
Mounting Hole Distance - Width:
1.38 in
Response Time:
Less Than14 msec (AC Operated Opening Delay), Less Than22 msec (AC Operated Closing Delay), Less Than30 msec (DC Operated Opening Delay), Less Than47 msec (DC Operated Opening Delay)
Includes Auxiliary Contacts:
Yes
Mechanical Operating Durability:
10,000,000
Overall Height:
2 in
Maximum Voltage Rating:
690V AC
Horsepower @ Single Phase - 120V AC:
3 hp
Number of Auxillary Contacts:
1
Full Load Current - Inductive:
32 A
Package Quantity:
1
