IEC Magnetic Contactor, 3 Poles, 24 V DC, 32 A, Reversing: No - 3RT20271BB443MA0

IEC Magnetic Contactor, 3 Poles, 24 V DC, 32 A, Reversing: No - 3RT20271BB443MA0

Siemens
SKU:
3RT20271BB443MA0
|
UPC:
662643915884
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Magnetic Contactor, Auxiliary Contact Form 2NO/2NC, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 24V DC, Number of Poles 3, Full Load Current - Inductive 32 A, Full Load Current - Resistive 50 A, Reversing Capability Non-Reversing, Overall Height 3.6 in, Overall Width 2.2 in, Terminal Connection Type Screw Terminals, Frame Size S0, Mounting Style DIN Rail, Surface, Series SIRIUS 3RT Safety Contactors, Number of Auxillary Contacts 4, Contactor Style IEC
Additional Information
Country of Origin:
Germany
Full Load Amps-Inductive:
32 A
Item:
IEC Magnetic Contactor
Action:
Non-Reversing
Full Load Amps-Resistive:
50 A
Number of Poles:
3
Coil Volts:
24 V DC
Reversing:
No
HP @ 1 Phase - 120V:
2 hp
HP @ 1 Phase - 230V:
5
HP @ 1 Phase - 240V:
5 hp
Height:
1.77 in
Width:
1.77 in
HP @ 3 Phase - 208V:
10 hp
HP @ 3 Phase - 240V:
10 hp
Depth:
4.21 in
HP @ 3 Phase - 575V:
25 hp
HP @ 3 Phase - 480V:
20 hp
Enclosure NEMA Rating:
No Enclosure
Aux. Contact Configuration:
2NO/2NC
Auxiliary Contact Form:
2NO/2NC
Standards:
REACH Art 33, WEEE (2012/19/EU)
Frame / Series / Class / Code:
Frame B
Includes:
Permanent Mounted Aux Contact
Series:
SIRIUS 3RT Safety Contactors
NEMA Size:
Not Applicable
Watts Loss:
2.3W (Current Dependent); 5.9W (Current Independent)
Electrical Connection:
Screws
IP Rating:
IP20
Max. Operating Watts:
15 kW (at 400V, AC-3), 28 kW (at 400V, AC-1)
Number of Auxillary Contacts:
4
Horsepower @ Three Phase - 600V AC:
25 hp
Full Load Current - Resistive:
50 A
NEMA Enclosure Rating:
No Enclosure
Horsepower @ Single Phase - 240V AC:
5 hp
Number of Normally Open Main Contacts:
3
Contactor Style:
IEC
Mounting Hole Distance - Width:
1.38 in
Horsepower @ Three Phase - 240V AC:
10 hp
Response Time:
4 to 16 msec (Opening Delay at AC), 8 to 40 msec (Closing Delay at AC)
Horsepower @ Three Phase - 480V AC:
20 hp
Full Load Current - Inductive:
32 A
Mounting Hole Diameter:
0.19 in
Phase:
Three
Mechanical Operating Durability:
10,000,000
Minimum Operating Temperature:
-13 Degrees F
Mounting Style:
DIN Rail, Surface
Coil Voltage:
24V DC
Frame Size:
S0
Overall Width:
2.2 in
Horsepower @ Single Phase - 120V AC:
2 hp
Horsepower @ Three Phase - 208V AC:
10 hp
Terminal Connection Type:
Screw Terminals
Mounting Hole Distance - Height:
2.36 in
Maximum Operating Temperature:
140 Degrees F
NEMA Enclosure Material:
Not Applicable
Overall Height:
3.6 in
Maximum Voltage Rating:
690V AC
Reversing Capability:
Non-Reversing
Includes Auxiliary Contacts:
Yes
Overall Depth:
5 in
Mounting Postion:
Vertical
Embedded Surge Suppressor:
No
Package Quantity:
1
