IEC Magnetic Contactor, 3 Poles, 24 V AC, 18 A, Reversing: No - XTCE018C10T

IEC Magnetic Contactor, 3 Poles, 24 V AC, 18 A, Reversing: No - XTCE018C10T

Eaton
SKU:
XTCE018C10T
|
UPC:
786685363028
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Magnetic Contactor, Auxiliary Contact Form 1NO, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 24V AC, Number of Poles 3, Full Load Current - Inductive 18 A, Full Load Current - Resistive 40 A, Reversing Capability Non-Reversing, Overall Height 1.5 in, Overall Width 3.5 in, Terminal Connection Type Screw Terminals, Frame Size C, Mounting Style DIN Rail, Panel, Series XT, Number of Auxillary Contacts 1, Contactor Style IEC, Horsepower @ Three Phase - 240V AC 5 hp
Additional Information
Country of Origin:
Romania
Item:
IEC Magnetic Contactor
Full Load Amps-Inductive:
18 A
Full Load Amps-Resistive:
40 A
Action:
Non-Reversing
Type:
Full voltage non-reversing contactor
Number of Poles:
3
Coil Volts:
24 V AC
Reversing:
No
HP @ 1 Phase - 120V:
2 hp
HP @ 1 Phase - 230V:
3
Height:
1.77 in
HP @ 1 Phase - 240V:
3 hp
HP @ 3 Phase - 208V:
5 hp
Width:
1.77 in
Depth:
3.82 in
HP @ 3 Phase - 240V:
5 hp
HP @ 3 Phase - 575V:
15 hp
HP @ 3 Phase - 480V:
10 hp
Enclosure NEMA Rating:
No Enclosure
Aux. Contact Configuration:
1NO
Hz:
50/60
Frame / Series / Class / Code:
Frame C
Auxiliary Contact Form:
1NO
Standards:
CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
NEMA Size:
Not Applicable
Series:
XT
IP Rating:
IP20
Electrical Connection:
Screw Terminals
Product Height:
1.5 in
Contact Configuration:
1 NO
Amperage Rating:
18A
Product Length/Depth:
4 in
Compliances:
CE Marked
Certifications:
UL Listed;CSA Certified;IEC 60947;EN 60947
Hp Rating - Max:
2, 2, 3/ 5, 5, 10, 15 hp (1/3PH @115,200,230/200,230,460,575 V)
Product Width:
3.5 in
Product Name:
Eaton XT IEC contactor
Frequency Rating:
50-60 Hz
Coil Voltage:
24V AC
Horsepower @ Three Phase - 208V AC:
5 hp
NEMA Enclosure Rating:
No Enclosure
Electrical Operating Durability:
2,000,000
Overall Depth:
4 in
Overall Width:
3.5 in
Terminal Connection Type:
Screw Terminals
Horsepower @ Single Phase - 240V AC:
3 hp
Horsepower @ Three Phase - 600V AC:
15 hp
Mounting Style:
DIN Rail, Panel
Embedded Surge Suppressor:
Yes
Horsepower @ Three Phase - 480V AC:
10 hp
Mounting Hole Diameter:
0.16 in
Frame Size:
C
Minimum Operating Temperature:
-13 Degrees F
Maximum Voltage Rating:
690V AC
Frequency:
50/60 Hz
Mounting Hole Distance - Width:
1.38 in
Horsepower @ Three Phase - 240V AC:
5 hp
Maximum Operating Temperature:
122 Degrees F
Full Load Current - Inductive:
18 A
Horsepower @ Single Phase - 120V AC:
2 hp
Contactor Style:
IEC
Includes Auxiliary Contacts:
Yes
Response Time:
Less Than14 msec (AC Operated Opening Delay), Less Than22 msec (AC Operated Closing Delay), Less Than30 msec (DC Operated Opening Delay), Less Than47 msec (DC Operated Opening Delay)
Number of Auxillary Contacts:
1
Overall Height:
1.5 in
Reversing Capability:
Non-Reversing
Mechanical Operating Durability:
10,000,000
Full Load Current - Resistive:
40 A
Mounting Hole Distance - Height:
2.95 in
NEMA Enclosure Material:
Not Applicable
Package Quantity:
1
