IEC Magnetic Contactor, 3 Poles, 220/240 V AC, 9 A, Reversing: No - 3RT20161AP61

IEC Magnetic Contactor, 3 Poles, 220/240 V AC, 9 A, Reversing: No - 3RT20161AP61

Siemens
SKU:
3RT20161AP61
|
UPC:
40892634044
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Magnetic Contactor, Auxiliary Contact Form 1NO, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 220/240V AC, Number of Poles 3, Full Load Current - Inductive 9 A, Full Load Current - Resistive 22 A, Reversing Capability Non-Reversing, Overall Height 3.08 in, Overall Width 1.97 in, Terminal Connection Type Screw Terminals, Frame Size S00, Mounting Style DIN Rail, Surface, Series SIRIUS 3RT20, Number of Auxillary Contacts 1, Contactor Style IEC
Additional Information
Country of Origin:
Germany
Item:
IEC Magnetic Contactor
Full Load Amps-Inductive:
9 A
Full Load Amps-Resistive:
22 A
Action:
Non-Reversing
Number of Poles:
3
Coil Volts:
220/240 V AC
Reversing:
No
HP @ 1 Phase - 230V:
1
HP @ 1 Phase - 120V:
1/3 hp
HP @ 1 Phase - 240V:
1 hp
Height:
1.77 in
HP @ 3 Phase - 208V:
2 hp
Width:
1.77 in
HP @ 3 Phase - 575V:
7 1/2 hp
Depth:
2.87 in
HP @ 3 Phase - 240V:
3 hp
HP @ 3 Phase - 480V:
5 hp
Enclosure NEMA Rating:
No Enclosure
Aux. Contact Configuration:
1NO
Hz:
50/60
Standards:
REACH Art 33, WEEE (2012/19/EU)
Auxiliary Contact Form:
1NO
Frame / Series / Class / Code:
S00
NEMA Size:
Not Applicable
Series:
SIRIUS 3RT20
Watts Loss:
0.3W (Current Dependent); 4.4W (Current Independent)
Max. Operating Watts:
4 kW (at 400V, AC-3), 13 kW (at 400V, AC-1)
IP Rating:
IP20
Electrical Connection:
Screws
Response Time:
10 to 18 msec (AC Operation Closing Delay Operation Opening Delay Operating Times for 1.0 x Us1), 15 to 17.5 msec (DC Operation Opening Delay Operating Times For 0.8 ... 1.1 X Us1), 16 to 17.5 msec (DC Operation Opening Delay Operating Times for 1.0
Minimum Operating Temperature:
-13 Degrees F
Overall Depth:
2.45 in
Terminal Connection Type:
Screw Terminals
Horsepower @ Three Phase - 600V AC:
7 1/2 hp
Horsepower @ Three Phase - 480V AC:
5 hp
Mounting Hole Distance - Height:
1.97 in
Maximum Voltage Rating:
690V AC
Number of Auxillary Contacts:
1
Mounting Postion:
Vertical
Horsepower @ Three Phase - 208V AC:
2 hp
Mounting Style:
DIN Rail, Surface
Horsepower @ Single Phase - 240V AC:
1 hp
Includes Auxiliary Contacts:
Yes
Full Load Current - Resistive:
22 A
Number of Normally Open Main Contacts:
3
Frame Size:
S00
Horsepower @ Single Phase - 120V AC:
1/3 hp
NEMA Enclosure Rating:
No Enclosure
Frequency:
50/60 Hz
Coil Voltage:
220/240V AC
Horsepower @ Three Phase - 240V AC:
3 hp
Reversing Capability:
Non-Reversing
Phase:
Three
Overall Height:
3.08 in
Mechanical Operating Durability:
30,000,000
Mounting Hole Diameter:
0.2 in
Maximum Operating Temperature:
140 Degrees F
Embedded Surge Suppressor:
No
Overall Width:
1.97 in
Full Load Current - Inductive:
9 A
Mounting Hole Distance - Width:
1.38 in
Contactor Style:
IEC
NEMA Enclosure Material:
Not Applicable
Package Quantity:
1
