IEC Magnetic Contactor, 3 Poles, 208 V AC, 40 A, Reversing: No - LC1D40ALE7

IEC Magnetic Contactor, 3 Poles, 208 V AC, 40 A, Reversing: No - LC1D40ALE7

Schneider Electric
SKU:
LC1D40ALE7
|
UPC:
785901632351
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Magnetic Contactor, Auxiliary Contact Form 1NO/1NC, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 208V AC, Number of Poles 3, Full Load Current - Inductive 40 A, Full Load Current - Resistive 60 A, Reversing Capability Non-Reversing, Overall Height 4.8 in, Overall Width 2.17 in, Terminal Connection Type Screw Clamp Terminals, Mounting Style DIN Rail, Plate, Series TeSys Deca, Number of Auxillary Contacts 2, Contactor Style IEC
Additional Information
Country of Origin:
France
Item:
IEC Magnetic Contactor
Full Load Amps-Inductive:
40 A
Full Load Amps-Resistive:
60 A
Action:
Non-Reversing
Number of Poles:
3
Coil Volts:
208 V AC
Reversing:
No
HP @ 1 Phase - 230V:
5
HP @ 1 Phase - 120V:
3 hp
HP @ 1 Phase - 240V:
5 hp
Height:
2.17 in
HP @ 3 Phase - 208V:
10 hp
Width:
2.17 in
HP @ 3 Phase - 575V:
30 hp
Depth:
2.72 in
HP @ 3 Phase - 240V:
10 hp
HP @ 3 Phase - 480V:
30 hp
Enclosure NEMA Rating:
No Enclosure
Aux. Contact Configuration:
1NO/1NC
Hz:
50/60
Standards:
CCC, CSA, CSA C22.2 No 14, EN 60947-4-1, EN 60947-5-1, GOST, IEC 60335-1, IEC 60947-4-1, IEC 60947-5-1, UL 508, UL Listed
Auxiliary Contact Form:
1NO/1NC
Includes:
Everlink Power Connections
Series:
TeSys Deca
NEMA Size:
Not Applicable
Net Weight:
0.85 kg
Impulse Withstand Voltage:
6 kV
Non-Overlap Time:
1.5 ms
Vibration Resistance:
4 G (Contactor Closed), 2 G (Contactor Open)
Includes Protective Cover:
Yes
Features:
Without Built-In Suppressor Module
Insulation Resistance Range:
Greater Than 10 MOhms (Signalling Circuit)
IP Rating:
IP20
Overvoltage Category:
CAT III
Application:
Motor Control, Resistive Load
Thermal Amperage:
10 A (at 60°C Signalling Circuit), 60 A (at 60°C Power Circuit)
Rated Short-Time Withstand Current:
320 A (at 40°C for 10 s Power Circuit), 720 A (at 40°C for 1 s Power Circuit), 72 A (at 40°C for 10 min Power Circuit), 165 A (at 40°C for 1 min Power Circuit), 100 A (For 1 s Signalling Circuit), 120 A (For 500 ms Signalling Circuit), 140 A (For
Shock Resistance:
10 G for 11 ms (Contactor Open), 15 G for 11 ms (Contactor Closed)
Environmental Attributes:
Mercury Free, PVC Free, Toxic Heavy Metal Free, Pollution Degree 3
Rated Voltage:
690V AC, 300V DC
Operating Time:
4 to 19 ms (Opening), 12 to 26 ms (Closing)
Impedance:
1.5 mOhm
Tightening Torque:
1.7 Nm (Control Circuit), 2.5 to 8 Nm (Power Circuit)
Electrical Connection:
Control Circuit
Signalling Circuit Frequency:
25 to 400 Hz
Working Height:
Up to 9842.52 ft
Rated Breaking Capacity:
800 A @ 440V
Mechanical Durability:
6 Mcycles
Inrush VA:
140 VA
Fuse Amps:
10 A (Signalling Circuit), 80 A (Type 1 Power Circuit), 80 A (Type 2 Power Circuit)
Switching Current:
5 mA (Signalling Circuit)
Electrical Durability:
1.4 Mcycles (60 A, AC-1, Less than 440 V); 1.5 Mcycles (40 A, AC-3, Less than 440 V); 1.5 Mcycles (40 A, AC-3e, Less than 440 V)
Watts Loss:
4 to 5W
Max. Temperature:
850°C
Rated Insulation Volts:
600/690V
Fire Rating:
UL 94 V1
Mounts On:
Plate, Rail
Switching Voltage:
17 V (Signalling Circuit)
Control Circuit Voltage Limits:
Drop-Out AC
Operating Speed:
3600 cycles per hr
Rated Making Capacity:
140 A (AC Signalling Circuit), 250 A (DC Signalling Circuit), 800 A @ 440V (Power Circuit)
Hold VA:
13 VA
Max. Operating Watts:
18.5 kW (at 380 to 400V AC 50/60 Hz AC-3), 11 kW (at 220 to 230V AC 50/60 Hz AC-3), 22 kW (at 415 to 440V AC 50/60 Hz AC-3), 22 kW (at 500V AC 50/60 Hz AC-3), 30 kW (at 660 to 690V AC 50/60 Hz AC-3), 9 kW (at 400V AC 50/60 Hz AC-4), 18.5 kW (at 380 t
NEMA Enclosure Material:
Not Applicable
NEMA Enclosure Rating:
No Enclosure
Full Load Current - Resistive:
60 A
Minimum Operating Temperature:
-40 Degrees F
Horsepower @ Single Phase - 120V AC:
3 hp
Frequency:
50/60 Hz
Includes Auxiliary Contacts:
Yes
Full Load Current - Inductive:
40 A
Horsepower @ Single Phase - 240V AC:
5 hp
Coil Voltage:
208V AC
Horsepower @ Three Phase - 480V AC:
30 hp
Horsepower @ Three Phase - 600V AC:
30 hp
Overall Height:
4.8 in
Maximum Operating Temperature:
140 Degrees F
Phase:
Three
Contactor Style:
IEC
Reversing Capability:
Non-Reversing
Overall Width:
2.17 in
Resistance Properties:
Fire Resistant, Insulation Resistant
Maximum Voltage Rating:
690V AC
Terminal Connection Type:
Screw Clamp Terminals
Number of Normally Open Main Contacts:
3
Mechanical Operating Durability:
6,000,000
Horsepower @ Three Phase - 240V AC:
10 hp
Electrical Operating Durability:
1,400,000, 1,500,000
Mounting Style:
DIN Rail, Plate
Horsepower @ Three Phase - 208V AC:
10 hp
Embedded Surge Suppressor:
No
Overall Depth:
4.72 in
Number of Auxillary Contacts:
2
Package Quantity:
1
