IEC Magnetic Contactor, 3 Poles, 120 V AC, 9 A, Reversing: No - XTCE009B01A

IEC Magnetic Contactor, 3 Poles, 120 V AC, 9 A, Reversing: No - XTCE009B01A

Eaton
SKU:
XTCE009B01A
|
UPC:
786685363431
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Magnetic Contactor, Auxiliary Contact Form 1NC, NEMA Enclosure Rating No Enclosure, NEMA Size Not Applicable, Coil Voltage 110/120V AC, Number of Poles 3, Full Load Current - Inductive 9 A, Full Load Current - Resistive 22 A, Reversing Capability Non-Reversing, Overall Height 2 in, Overall Width 3 in, Terminal Connection Type Screw Terminals, Frame Size B, Mounting Style DIN Rail, Panel, Series XT, Number of Auxillary Contacts 1, Contactor Style IEC, Horsepower @ Three Phase - 240V AC 3 hp
Additional Information
Country of Origin:
Romania
Full Load Amps-Inductive:
9 A
Item:
IEC Magnetic Contactor
Full Load Amps-Resistive:
22 A
Action:
Non-Reversing
Type:
Full voltage non-reversing contactor
Number of Poles:
3
Coil Volts:
120 V AC
Reversing:
No
HP @ 1 Phase - 120V:
1/2 hp
HP @ 1 Phase - 230V:
1-1/2
Height:
1.77 in
HP @ 1 Phase - 240V:
1 1/2 hp
HP @ 3 Phase - 208V:
3 hp
Width:
1.77 in
HP @ 3 Phase - 240V:
3 hp
HP @ 3 Phase - 575V:
7 1/2 hp
Depth:
2.95 in
HP @ 3 Phase - 480V:
5 hp
Enclosure NEMA Rating:
No Enclosure
Aux. Contact Configuration:
1NC
Hz:
50/60
Auxiliary Contact Form:
1NC
Standards:
CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
Frame / Series / Class / Code:
Frame B
NEMA Size:
Not Applicable
Series:
XT
Electrical Connection:
Screw Terminals
IP Rating:
IP20
Amperage Rating:
9A
Product Width:
3 in
Compliances:
CE Marked
Frame Size:
B
Product Height:
2 in
Product Length/Depth:
2.75 in
Product Name:
Eaton XT IEC contactor
Contact Configuration:
1 NC
Coil Voltage:
110/120V AC
Frequency Rating:
50-60 Hz
Hp Rating - Max:
0.5, 1, 1.25/ 3, 3, 5, 7.5 hp (1/3PH @115,200,230/200,230,460,575 V)
Certifications:
UL Listed;CSA Certified;IEC 60947;EN 60947
Overall Width:
3 in
Maximum Voltage Rating:
690V AC
Embedded Surge Suppressor:
Yes
Mounting Style:
DIN Rail, Panel
Frequency:
50/60 Hz
Overall Height:
2 in
Overall Depth:
2.75 in
Full Load Current - Inductive:
9 A
Contactor Style:
IEC
Number of Auxillary Contacts:
1
NEMA Enclosure Rating:
No Enclosure
NEMA Enclosure Material:
Not Applicable
Includes Auxiliary Contacts:
Yes
Electrical Operating Durability:
1000 (AC-3 400V Ie), 300 (AC-4 400V Ie), 800 (AC-1 400V Ie)
Horsepower @ Three Phase - 600V AC:
7 1/2 hp
Horsepower @ Three Phase - 208V AC:
3 hp
Reversing Capability:
Non-Reversing
Horsepower @ Single Phase - 240V AC:
1 1/4 hp
Maximum Operating Temperature:
122 Degrees F
Mechanical Operating Durability:
10,000,000
Horsepower @ Three Phase - 240V AC:
3 hp
Response Time:
Less Than12 msec (DC Operated Opening Delay), Less Than18 msec (AC Operated Opening Delay), Less Than21 msec (AC Operated Closing Delay), Less Than31 msec (DC Operated Opening Delay)
Full Load Current - Resistive:
22 A
Minimum Operating Temperature:
-13 Degrees F
Terminal Connection Type:
Screw Terminals
Horsepower @ Single Phase - 120V AC:
1/2 hp
Horsepower @ Three Phase - 480V AC:
5 hp
Package Quantity:
1
