IEC Control Relay2NO/2NC24VAC16A - XTRE10B22T

IEC Control Relay2NO/2NC24VAC16A - XTRE10B22T

Eaton
SKU:
XTRE10B22T
|
UPC:
786685364599
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
IEC Control Relay, Current Rating 10 A, Contact Form 2NO/2NC, Contact Rating (DC) 10 A @ 24V, Coil Voltage 24V AC, Contact Rating (AC) 6 A @ 240V, Relay Style IEC, Electrical Connection Screw Terminal, Mounting Style DIN Rail, Power Consumption 3.3 VA, IP Rating IP20, Frame Size 45 mm, NEMA Size Not Applicable, Compatible with Series XTRE Control Relays, Maximum Operating Temperature 140 Degrees F, Frequency 50/60 Hz, Body Depth 2.97 in, Body Height 2 in, Body Width 1.77 in
Additional Information
Country of Origin:
Romania
Item - Relay:
IEC Style Control Relay
Coil Volts:
24V AC
AC Contact Rating - Relay:
6A @ 240V
DC Contact Rating - Relay:
10A @ 24V
Number of Pins - Relay:
10
Contact Form - Relay:
(2) SPST-NC, (2) SPST-NO
Mounting - Relay:
DIN Rail
Body Height - Relay:
2.68 in
Contact Form:
2NO/2NC
Mounting:
Din Rail
Body Depth - Relay:
2.95 in
Hz - Electrical:
50 Hz, 60 Hz
Features:
4-Pole Configurations, Available with Screw or Spring Cage Terminals, IP20 Finger and Back-of-Hand Proof
Hz:
50/60
Item:
IEC Control Relay
Coil Rating:
25VA Inrush, 3.3VA Sealed
Response Time:
15 to 21 msec (Closing Delay), 9 to 18 msec (Opening Delay)
Power Consumption - Relay:
3.3 VA
Contact Material:
Silver Tin Oxide Alloy
Overall Height - Relay:
2.68 in
Standards:
UL Listed
Contact Amp Rating (Resistive):
16A
Body Width - Relay:
1.77 in
Product Width:
3 in
Frame size:
45 mm - standard
Certifications:
UL Listed
Contact configuration:
2 NO, 2 NC
Conventional thermal current:
10A
Product Height:
2 in
Coil:
24 Vac, 50/60 Hz
Rated operational current:
4 A at 380/400/415 V
Terminals:
Screw terminals
Product Length/Depth:
3 in
Type:
Control relay
Product Name:
Eaton XT IEC control relay
Maximum Operating Temperature:
140 Degrees F
Input Voltage:
24V AC
Power Consumption:
3.3 VA
Minimum Operating Temperature:
-13 Degrees F
Coil Voltage:
24V AC
For Use With:
Contactors, Starters
Frame Size:
45 mm
Number of Pins:
10
Compatible with Series:
XTRE Control Relays
Contact Rating (DC):
10 A @ 24V
Mechanical Operating Durability (DC):
20,000,000
Electrical Connection:
Screw Terminal
Weight:
0.5 lb
Body Height:
2 in
Mounting Style:
DIN Rail
IP Rating:
IP20
Frequency:
50/60 Hz
Mechanical Operating Durability (AC):
20,000,000
Overall Height:
2.68 in
Body Width:
1.77 in
Body Depth:
2.97 in
Contact Rating (AC):
6 A @ 240V
Relay Style:
IEC
Current Rating:
10 A
NEMA Size:
Not Applicable
Package Quantity:
1
