Hydronic Circulating Pump, 1/12 hp, 115V, 1 Phase, Flange Connection - 106197LF

Hydronic Circulating Pump, 1/12 hp, 115V, 1 Phase, Flange Connection - 106197LF

Bell & Gossett
SKU:
106197LF
|
UPC:
683328223612
Availability:
In Stock

Log in for pricing

(No reviews yet)
Current Stock:
Description
Potable Water Circulating Pump, Compatible Intake Pipe Size 3/4 in, 1 in, 1 1/4 in, 1 1/2 in, Connection Type Flange, Face to Face Dimension 6 3/8 in, Flange or Union Included No, For Use With Potable Systems Yes, Horsepower 1/12, Maximum Feet of Head 8 ft, Maximum Flow Rate @ 1 Foot of Head 32 gpm, Nameplate Voltage 115V AC, Number of Speeds 1, Phase Single, Pump Type 3-Piece, Series Family Series 100, Maximum Flow Rate @ 5 Feet of Head 22 gpm, Series 100 BNFI, Amps 1.75 A
Additional Information
Country of Origin:
United States
Item:
Potable Water Circulating Pump
Voltage:
115V AC
Phase:
Single
Horsepower:
1/12
Series:
100 BNFI
Inlet/Outlet Size:
3/4 in to 1-1/2 in
Pump Type:
3-Piece
Number of Speeds:
1
Max. GPM @ Head:
32 gpm @ 1 ft
Maximum Feet of Head:
8 ft
Min. GPM @ Head:
5 gpm @ 8 ft
Connection Type:
Flange
Shut-Off:
8 ft
Face to Face Dimension:
6 3/8 in
Best Efficiency GPM @ Head:
17 gpm @ 6 ft
Loop Configuration:
Open
Impeller Material:
Polypropylene
Drive Type:
Direct
Mechanical Seal:
Bell and Gossett Motor
Thermal Protection:
yes
Shaft Material:
Carbon/Ceramic
Pump Mount:
NFI
Amps:
1.75 A
Standards:
CSA, UL Listed
Frequency:
60 Hz
Maximum Media Temperature:
225 Degrees F
Compatible Discharge Pipe Size:
3/4 in, 1 in, 1 1/4 in, 1 1/2 in
Compatible Media Type:
Oil
Nameplate Voltage:
115V AC
Maximum Operating Pressure:
125 psi
Maximum RPM:
1,725 RPM
Pump Housing Material:
Bronze
Manufacturer Warranty Length:
1 yr
Overall Width:
6.38 in
Compatible Intake Pipe Size:
3/4 in, 1 in, 1 1/4 in, 1 1/2 in
Series Family:
Series 100
Flange or Union Included:
No
Motor Enclosure Design:
Open Drip-Proof
Maximum Flow Rate @ 10 Feet of Head:
32 gpm
Overall Length:
14.88 in
Maximum Flow Rate @ 50 Feet of Head:
[DELETE]
For Use With Potable Systems:
Yes
Maximum Flow Rate @ 5 Feet of Head:
22 gpm
Maximum Flow Rate @ 1 Feet of Head:
32 gpm
Package Quantity:
1
